10/100/1000BASE-T Gigabit Ethernet Auto Negotiation Copper GBIC Transceiver Module

10/100/1000BASE-T Gigabit Ethernet Auto Negotiation Copper GBIC Transceiver Module

Afficher tous les détails
Features
  • Hot-pluggable GBIC footprint
  • Extended case temperature range (0°C to +70°C )
  • Fully metallic enclosure for low EMI
  • Low power dissipation (1.05 W typical)
  • Compact RJ-45 connector assembly
  • Access to physical layer IC via 2-wire serial bus
  • 10/100/1000Mbps compliant in host systems with SGMII interface
  • The ING-TX has an input voltage range of +5/- 5V.
  • The 5V maximum voltage is not allowed for continuous
Specifications
  • Part Number: G1GT-A
  • Device Type: Copper GBIC
  • Package: GBIC
  • Data Rate: 1.25Gbps
  • Wavelength: -
  • Distance/Power Budget: 100m
  • Optical Components
    • LD: -
    • PD: -
  • Output Power: -
  • Receiver Sensitivity: -
  • Power Supply Voltage: 3.3V/5V
  • Connector: Single RJ45
  • Fiber Type: Cu
  • Operating Temperature: 0~70 °C
  • DDMI: Without
  • Application: Ethernet
  • Compatiblity: All Brands

F-tone is the original manufacturer of Copper GBIC G1GT-A - 10/100/1000BASE-T Gigabit Ethernet Auto Negotiation Copper GBIC Transceiver Module . We have ready stock for G1GT-A and can ship it out in two business days. We guarantee the G1GT-A transceiver module to work in your system and all of our G1GT-A transceiver modules come with a lifetime warranty.

The G1GT-A is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The G1GT-A must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Tout afficher

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Tout afficher

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
