10/100/1000M Gigabit Ethernet 1 GE SFP port & 1 RJ45 port SFP Media Converter

10/100/1000M Gigabit Ethernet 1 GE SFP port & 1 RJ45 port SFP Media Converter

Afficher tous les détails

This 10/100/1000M Gigabit Ethernet SFP media converter is designed to meet the massive needs for network deployment and able to extend a copper based Gigabit network via fiber cable to a maximum distance up to 120km.

The series SFP media converters are fully compliant with IEEE802.3 & 802.3u, 10/100/1000BASE-T, 1000BASE-X standards. It can be installed into a standard converter chassis. The installation & operation procedures are simple & straightforward. Operation status can be locally monitored through a set of Diagnostic LED located in the front panel.

Features & Specifications

  • 10/100/1000Base-T to 1000Base-X SFP Media Converters
  • Standards: IEEE802.3 & 802.3u, 10/100/1000BASE-T, 1000BASE-X
  • Interface: 1 x RJ45 connector, 1 x SFP slot
  • Flow Control: IEEE802.3x flow control for full duplex mode, Back-pressure flow control for half duplex mode.
  • LED Indication: PWR, FX,FX-LINK/ACT, FDX/CCL, 1000M , TX-LINK/ACT
  • Power: External power supply
  • Dimension: 95 ×70 ×26mm(out) power external

The SFP media converter has one empty SFP slot for Cisco and other industry standard GE SFPs

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Tout afficher

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Tout afficher

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
