10/100M Fast Ethernet 1 FX port & 1 RJ45 port Dual-Fiber Media Converter

10/100M Fast Ethernet 1 FX port & 1 RJ45 port Dual-Fiber Media Converter

Afficher tous les détails

SA-FE-1F1T series media converter complies with IEEE802.3 standards, It is designed to convert data signal between 10/100 Base-TX and 100 Base-FX fast Ethernet. The media converter is connected between Fiber cable and twisted cable segments with network operating smoothly. This converter can be used as a standalone unit or as a slide-in module to media converter rack RACK-14 (up to 14 units) for use at a central wiring closet. It can be used  all areas such as Fiber to The Home, Fiber to the Business or Fiber to The Curb.

Features

  • 10/100Mbps and full/half duplex automatically configure in TP port.
  • Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX, 100Base-FX Standards
  • MDI/MDI-X Auto Negotiation
  • LED Indicators: POWER, FX LINK/ACT, 100, TP LINK/ACT, FDX/COL.
  • Supports 19” System Chassis (RACK-14),  holds up to 14 Media Converters
  • Hot Pluggable & Wall-Mountable
  • ROHS & CE approved


Specifications

  • Standard Compliance: IEEE802.3u 10/100Base-TX, 100Base-FX
  • Data Transfer Rate
    • 100Mbps:148,800 pps
    • 10Mbps:14,880 pps
  • Buffer Memory: 128K
  • Connectors
    • 1 x RJ45: 10/100Mbps (Auto-negotiation)
    • 1 x Duplex ST/SC/LC: 100Mbps
  • Cable
    • TP: Cat.5 (Support distance up to 100m)
    • Fiber (M-M):50/125,2.5/125,100/140£gm(Support distance up to 2Km)
    • Fiber (S-M):8.3/125,8.7/125,9/125,100/125£gm (Support distance up to 120Km)
  • Flow Control
    • IEEE802.3x compliant for full-duplex
    • Backpressure flow control for half-duplex
  • Maximum distance: Multimode;2km(Default), Single-mode;20km/(Default)40km/60km/80km/100km/120km
  • Power Supply: External, Built-in or USB
  • Dimensions: 26.2(H) x 70.3(W) x 94(D) mm
  • Weight: 0.2kg
  • Environment
    • Relative humidity: 5% to 90%
    • Operating temperature: 0 to 70
    • Storage temperature: -20 to 85

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
