125Mbps Fast Ethernet 1310nm Single-mode Dual LC 20km SGMII SFP Module for GE SFP port

125Mbps Fast Ethernet 1310nm Single-mode Dual LC 20km SGMII SFP Module for GE SFP port

Afficher tous les détails

Description

Features 1310nm Laser and PIN Photo-Detector Distance Up to 20 km over SMF Build-in PHY supporting SGMII Interface Support More Link Status Monitor, Such as CRC, Package Counter and Far End Faut Indication(FEFI) Single 3. 3V Power Supply and TTL Logic Interface Compliant with SFP MSA package with duplex LC Connector Standard Serial ID information Compliant with SFP MSA Specifications Part Number: SGE-FX-20 Device Type: GE-FX SFP Package: SFP Data Rate: Mac-1.25Gbps/ Fiber-125Mbps Wavelength: 1310nm Distance/Power Budget: 20km Optical Components LD: FP PD: PIN Output Power: -15~-8dBm Receiver Sensitivity: -31dBm Power Supply Voltage: 3.3V Connector: Dual LC Fiber Type: SMF Operating Temperature: 0~70 °C DDMI: Without Application: Ethernet Compatiblity: All Brands F-tone is the original manufacturer of GE-FX SFP SGE-FX-20 - 125Mbps Fast Ethernet 1310nm Single-mode Dual LC 20km SGMII SFP Module for GE SFP port. We have ready stock for SGE-FX-20 and can ship it out in two business days. We guarantee the SGE-FX-20 transceiver module to work in your system and all of our SGE-FX-20 transceiver modules come with a lifetime warranty. The SGE-FX-20 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The SGE-FX-20 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

These generic SFP transceivers are programmed to be compatible with a wide variety of switch brands. If you need specific switch brand compatibility, we offer custom labeling options including your company name, logo, part number, serial number, and barcode.

Please contact us to discuss your specific requirements.

Important Notice

Every module is tested before shipment. If you need a datasheet for this product or can't find a compatible module from us, please contact us. We also provide a wide variety of OEM/ODM solutions.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Tout afficher

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Tout afficher

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests

About F-tone Networks

F-tone Networks is now a world leader in development of optical transceivers and provide a wide range of high-speed optical solutions for optical communication networking, especially for AI, Data Center, enterprise data networking, Industry, aerospace, mining, shipbuilding, railway, metro, long haul transport networking, and mobile access networking applications
F-tone Networks invested in foundational photonics technologies and extensive product development and engineering with global presence in many area also.
