12 Fibers FM (05) A-24A LC Outdoor Wall Mountable Fiber Terminal Box as Distribution Box with Pigtails and Adapters

12 Fibers FM (05) A-24A LC Outdoor Wall Mountable Fiber Terminal Box as Distribution Box with Pigtails and Adapters

Afficher tous les détails

Part Number: 12F-LC-FTB-AFM

12 Fibers FM(05) A-24A LC Full set of Wall Mounted Metal Fiber Terminal Box as Distribution Box with Pigtails and Adapters

FTB Series FTTH customer terminal box is used in the end termination of residential buildings and villas, to fix and splice with pigtails. We offer the full set of plastic terminal box as distribution box, including 0.9mm pigtail and related adapter.

Note: Our default metal distribution box with Singlemode UPC connector 0.9mm fiber pigtails and adapters corresponding number of fibers. If you have special demands, just email us: [email protected]

Features

  • Small size, pleasing in appearance
  • Wall mounted with mechanical protection function
  • Max fiber capacity 12 fibers
  • Available for LC duplex adapers (Optional SM, MM or APC/SM)
  • Pigtails: 1.5m 12 fibers pigtails
  • Meterial: Metal
  • Hinge and convenient press-pull button lock design

Applications

  • Widely used in FTTH access network.
  • Telecommunication Networks
  • CATV Networks
  • Data Communications Networks
  • Local Area Networks

Make To Order

Fiber Mode Fiber Count Connector Type
Singlemode
4 Fibers (Plastic)
8 Fibers (Plastic)
12 Fibers (Metal)
24 Fibers (Metal)
FC/SC/ST/LC - UPC
FC/SC/ST/LC - APC
(APC only applicable to SM)
Multimode

Packaging

1xMetal Terminal Box + 1x0.9mm 12 Fiber Pigtails + 6 x SC Duplex Adapters

Kindly Remind

As the box is big, it defaults to the 12 fiber bunch pigtails. The metal distribution box also matches the pigtails with 12 different colors, if you need, please specify when ordering.F-tone offers all LC Distribution Boxes will be made SC duplex type Distribution Box


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
