2.67Gbps Multi-rate 1310nm Single-mode Dual LC 40km SFP Fiber Optic Transceiver Module

2.67Gbps Multi-rate 1310nm Single-mode Dual LC 40km SFP Fiber Optic Transceiver Module

Afficher tous les détails

Description

Features Hot-Pluggable SFP Footprint LC Optical Transceiver Small Form-Factor Pluggable (SFP) MSA compatible Compliant with SONET OC-48 (LR-1) / SDH STM-16 (L-16.1) Compliant with Fibre Channel 1x/2x SM-LC-L FC-PI Compliant with IEEE 802.3z 1000BASE 1310 nm DFB LD Transmitter APD High Sensitivity Receiver 26 dB Power Budget at Least AC/AC Coupling according to MSA Single +3.3 V Power Supply RoHS Compliant Class 1 Laser International Safety Standard IEC-60825 Compliant Specifications Part Number: SMR13-40 Device Type: Multi-rate SFP Package: SFP Data Rate: 125Mbps~2.67Gbps Wavelength: 1310nm Distance/Power Budget: 40km Optical Components LD: DFB PD: APD Output Power: -2~3dBm Receiver Sensitivity: -28dBm Power Supply Voltage: 3.3V Connector: Dual LC Fiber Type: SMF Operating Temperature: 0~70/ -10~80/ -40~85 °C DDMI: With/ Without Application: GE/ SONET/ SDH/ FC Compatiblity: All Brands F-tone is the original manufacturer of Multi-rate SFP SMR13-40 - 2.67Gbps Multi-rate 1310nm Single-mode Dual LC 40km SFP Fiber Optic Transceiver Module. We have ready stock for SMR13-40 and can ship it out in two business days. We guarantee the SMR13-40 transceiver module to work in your system and all of our SMR13-40 transceiver modules come with a lifetime warranty. The SMR13-40 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The SMR13-40 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

These generic SFP transceivers are programmed to be compatible with a wide variety of switch brands. If you need specific switch brand compatibility, we offer custom labeling options including your company name, logo, part number, serial number, and barcode.

Please contact us to discuss your specific requirements.

Important Notice

Every module is tested before shipment. If you need a datasheet for this product or can't find a compatible module from us, please contact us. We also provide a wide variety of OEM/ODM solutions.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Tout afficher

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Tout afficher

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
