4.25Gbps Single-mode 1550nm 4X/2X/1X Fiber Channel Dual LC 100km SFP Optical Transceiver Module

4.25Gbps Single-mode 1550nm 4X/2X/1X Fiber Channel Dual LC 100km SFP Optical Transceiver Module

Afficher tous les détails

Description

Features Specifications Part Number: S4G15-100 Device Type: FC SFP Package: SFP Data Rate: 4.25/2.125/1.0625Gbps Wavelength: 1550nm Distance/Power Budget: 100km Optical Components LD: DFB PD: APD Output Power: 2~7dBm Receiver Sensitivity: -27dBm Power Supply Voltage: 3.3V Connector: Dual LC Fiber Type: SMF Operating Temperature: 0~70/ -10~80/ -40~85 °C DDMI: With/ Without Application: Multi-rate FC Compatiblity: All Brands F-tone is the original manufacturer of FC SFP S4G15-100 - 4.25Gbps Single-mode 1550nm 4X/2X/1X Fiber Channel Dual LC 100km SFP Optical Transceiver Module. We have ready stock for S4G15-100 and can ship it out in two business days. We guarantee the S4G15-100 transceiver module to work in your system and all of our S4G15-100 transceiver modules come with a lifetime warranty. The S4G15-100 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The S4G15-100 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

These generic SFP transceivers are programmed to be compatible with a wide variety of switch brands. If you need specific switch brand compatibility, we offer custom labeling options including your company name, logo, part number, serial number, and barcode.

Please contact us to discuss your specific requirements.

Important Notice

Every module is tested before shipment. If you need a datasheet for this product or can't find a compatible module from us, please contact us. We also provide a wide variety of OEM/ODM solutions.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Tout afficher

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Tout afficher

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
