Mellanox MC2207130-005 Compatible 56G FDR QSFP+ to QSFP+ Copper Direct Attach Cable 5m (16ft)

Mellanox MC2207130-005 Compatible 56G FDR QSFP+ to QSFP+ Copper Direct Attach Cable 5m (16ft)

Afficher tous les détails

Part Number: 56G-FDR-QSFP-DAC5M

Mellanox MC2207130-005 Compatible 56G FDR QSFP+ Twinax Copper Cable (QSFP+ to QSFP+ DAC Cable, Passive AWG26 5m)

The F-tone 56G QSFP+ to QSFP+ direct attach cable runs on passive copper wire, ensuring connection quality without the need for additional power. The DAC complies with IEEE802.3cd and SFF-8432 standards. Available in various wire gauge options from 30 to 24 AWG, and various cable length options (up to 7m). It is suitable for cost-effective short-distance interconnection in telecom operators or data center computer rooms, and LAN or SAN applications with interconnection speeds up to 50G.

Product Details

Mellanox Compatible MC2207130-005 Vendor Name F-tone
Connector QSFP+ to QSFP+ Max Data Rate 56Gbps
Cable Length 5m (16.4ft) AWG AWG 26
Jacket Material PVC(OFNR) Minimum Bend Radius 45mm
Operation Temperature 0~ 70 ～C (32 to 158～F) Protocols 56G InfiniBand / SFF- 8436


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Tout afficher

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Tout afficher

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
