LC/UPC to LC/UPC Quad 4Fibers OS2 Singlemode Fiber Adapter

LC/UPC to LC/UPC Quad 4Fibers OS2 Singlemode Fiber Adapter

Afficher tous les détails

Part Number: AD-LCU-LCU-4C-SM-FM

OS2 Singlemode LC/UPC to LC/UPC Quad 4Fibers Fiber Adapter

A fiber optic adapter, sometimes also called a coupler, is a small device designed to terminate or link the fiber optic cables or fiber optic connectors between two fiber optic lines.

By linking two connectors precisely, fiber optic adapters allow the light sources to be transmitted at most and lower the loss as much as possible. At the same time, fiber optic adapters have the merits of low insertion loss, good interchangeability and reproducibility. FS supplies a wide range of mating sleeves and hybrid adapters, including special male to female hybrid fiber optic adapters.

Features

● ≤0.2dB(Typical) Low Insertion Loss

● Color Coded for Rapid Fiber Management

● 2x Duplex Dust Cap Keeps Adapter’s Interior Clean from Dust

● Stainless Steel Clips for Tool-less Snap-in Installation

● Available in A Variety of Connector Types

● Can be Used with M2 Model Screw

Specifications

Connector Type LC-LC Body Style Quad
Polish Type UPC Fiber Mode OS2 9/125μm
Insertion Loss ≤0.2dB Durability 1000 times
Mounting Type Full Flanged Alignment Sleeve Material Ceramic
Color Blue Flammability Rate UL 94V-0
Package Quantity 1 Pc RoHS Compliancy Status Compliant
Operating Temperature 40 to 85℃(-40 to 185℉) Storage Temperature -10 to 60℃(14 to 140℉)


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
