Cat7 RJ45 (8P8C) Shielded Toolless Keystone Jacks F-tone

Cat7 RJ45 (8P8C) Shielded Toolless Keystone Jacks F-tone

Afficher tous les détails

Part Number: C7M-STK-FM

RJ45 Toolless Shielded Keystone Jack for Cat7 Ethernet Networking


F-tone.COM provides keystone Cat7 toolless style connectors which make for a simple installation without the need for a punch down tool. Toolless keystone jacks are an ideal solution for terminating and connecting network cable.

Product Specifications

Product Type Cat7 Keystone Jack Color Metal silver
Connector RJ45 Female Termination Type Toolless
Shielding Type Shielded Data Rate Support 10GBase-T
Wire Gauge Supported 22-26AWG Cable Wiring Scheme T568A & T568B
Housing Material Zinc Alloy Dimensions (HxW) 16×14.5mm
Operating Temperature -10°C to 60°C (-14°F to 140°F) Storage Temperature -40°C to 70°C (-40°F to 158°F)
Quality Certifications

Product Highlights

Cat6a Toolless Keystone Network Jack Module
  • Easy installation requires no punch down tool
  • Use with a wall-plate for network wiring installs
  • Designed for high-speed network applications
  • Shielded STP Cover

    Designed for protection from external radiated noise

  • 50 µinch Gold Plating

    On the jack contacts for durability and a long lifespan

  • T568A/B Wiring Scheme

    Color-wiring diagram for ease of installation

Installation for STP Toolless Keystone Module

Designed for superior performance, this jack provides a simple process to connect your cable and will work with wall plates or patch panel.


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
