100GBASE-SR10 CFP 850nm 150m Transceiver for MMF

Part Number: CFP-100G85-1M

100GBASE-SR10 CFP 850nm 150m Transceiver for MMF

F-tone.Com's CFP-100G85-1M-xx 100G CFP module supports link lengths of 100 meters and 150 meters respectively on laser-optimized OM3 and OM4 multifiber cables. It primarily enables high-bandwidth 100-gigabit links over ribbon cables terminated with MPO/MTP connectors. It can also be used in 10 x 10 Gigabit Ethernet mode along with ribbon to duplex fiber breakout cables for connectivity to ten 10GBASE-SR optical interfaces. Maximum channel insertion loss allowed is respectively 1.9 dB over 100m of OM3 cable or 1.5 dB over 150m of OM4 cable.

Key Feature

• Compliant to the IEEE 802.3ba(100GBASE-SR10)
• Operates at 10.3125Gbps per channel
• Short wavelength over 10 lanes, 840 to 850nm
• VCSEL array transmitter and PIN array receiver
• Up to 100m on OM3 and 150m on OM4 MMF
• Utilizes a standard MPO/MTP Connector
• Support interoperability with IEEE 802.3ae 10GBASE-SR modules of various form factors such as SFP+, XFP, X2
• Compliant to the CFP MSA Specification
• Single 3.3V Power Supply
• The maximum power consumption per CFP-100G-SR10 module is 12W
• Operating case temperature: 0°C to +70°C
• MDIO digital diagnostic interface and control capabilities

Applications

• 100GBE and 10GBE interconnects
• Datacom/Telecom switch & router connections
• Data aggregation and backplane applications
• Proprietary protocol and density application

Ordering Information

Notes

• xx means compatible brand. (For example: CO= Cisco, JU=Juniper, FD=Foundry, EX=Extreme, NE=Netgear,etc.)

Packaging

• Antistatic bag
• Packed on pallets in a box(Default Customer Options)
• Specific Labels as Request
• Seperate white Box for each transceiver

OEM and ODM

Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, F-tone provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for F-tone in the world.

• OEM/ODM order is available
• We can supply CFP-100G85-1M according to your requirements, and design CFP-100G85-1M label and packaging for your company. We welcome any inquiry for customized 100G optical transceiver.

Order Procedure

Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
a. Email ([email protected]) us a rough sketch to a detailed drawing.
b. Our engineer will review the project and provide a quotation within 24 hours.
c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.

Shipment

International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.

Save Cost By Buying 100G Optical Transceiver From Original Manufacturer F-tone Directly.

F-tone is a professional manufacturer supplier of 100G optical transceiver . All of our 100G optical transceiver are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee 100G optical transceiver to work in your system and all of our 100G optical transceivers come with a lifetime advance replacement warranty. If you have questions about 100G optical transceiver, please feel free to contact us at [email protected].

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
