Cisco GLC-FE-100FX Compatible 100BASE-FX SFP Industrial Module - F-tone

Cisco GLC-FE-100FX Compatible 100BASE-FX SFP Industrial Module - F-tone

Afficher tous les détails

Transceivers Type

SFP Optical Transceiver

Compatible

200+ Vendors

Specifications

Cisco GLC-FE-100FX-RGD Compatible 100BASE-FX SFP Industrial Transceiver Module (MMF, 1310nm, 2km, LC, DOM)



Cisco GLC-FE-100FX-RGD 100BASE-FX transceiver module provides a maximum transmission data rate at 100Mbps, reaching a link up to 2km over multimode fiber, the GLC-FE-100FX-RGD work at 1310 nm wavelength with duplex LC connector. Besides, DOM is supported for real-time monitoring and is compatible with IEEE 802.3U standards. F-tone Transceiver Module tested in various brand switches and all Cisco devices can be well connected with high compatibility. Cisco GLC-FE-100FX-RGD transceiver module enables cost-effective solutions in the data center, and campus network applications.



Part Number FT-SFP-0102D Vendor Name F-tone
Form Factor SFP Data Rate 100Mbps
Wavelength 1310nm Max Cable Distance 2km
Connector Duplex LC Optical Components FP 1310nm
Media MMF DOM Support Yes
TX Power -15~-8dBm Receiver Sensitivity < -32dBm
Industrial Temperature Range -40 to 85°C (-40 to 185°F) Protocols IEEE802.3U, GR-468, MSA Compliant

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Tout afficher

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Tout afficher

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
