DVP-750 Digital Single Fiber Optic Fusion Splicer

DVP-750 Digital Single Fiber Optic Fusion Splicer

Afficher tous les détails

Part Number: DVP-750

DVP-750 Digital Single Fiber Optic Fusion Splicer

Features

High-definition LCD display
PAS Technology
Core or Cladding alignment
Double Heaters, 30 sec. Tube-heat time
3 Magnification modes, max. 360 magnification
4 Display modes, Fiber core visible
8 sec. splice time
Lithium battery
Max. wind velocity of 15m/s
Splicing method: Auto, Manual
Store 8000 groups of splice results
USB interface

Standrad Package

Main body, Internal Battery, Carry Case, Fiber Cleaver, Charger, Spare Electrodes, Fiber Stripper, AC Adaptor, Cooling Tray, Manual Instruction, AC Power Cord
Fiber Optic Fusion splicer is a must in the process of properly joining two bare optical fibers together. For this kind of fine workmanship product, we F-tone.com provide one year warranty for each domestic and foreign brand product. If you have any problems or special requirement of the DVP-750 Digital Single Fiber Optic Fusion Splicer, please feel free to contact us. We will try our best to provide you the best service.

Specifications

Applicable fibers SM, MM, NZ-DS(G655), EDF and others
Average splice loss 0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS)
Return loss ≥60dB
Tension test 2.0N (200gf) (Standard)
Protection sleeve length 20mm, 40mm, 60mm and other series micro protection sleeves
Splicing program 80 groups
Language English, Chinese, Korean, Russian, Spanish , French, German,
Portuguese and others
Environment conditions -25°C+50°C(operation temperature), 0~95%RH (humidity), 0~5000m (altitude)
Storage environment -40°C~+80°C(temperature) , 0~95% RH (humidity)
Power supply AC adaptor: 85~260V input voltage
Internal battery: 12V,8Ah, up to 180 times of continuous splice and heat
Dimensions/Weight 140(D)×150(W)×160(H)mm/2.8kg


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
