Finisar FTLX3811M3xx Compatible 10GBASE 100GHz DWDM SFP+ 80km Transceiver

Finisar FTLX3811M3xx Compatible 10GBASE 100GHz DWDM SFP+ 80km Transceiver

Afficher tous les détails

Part Number: DWDM-XFP10G-80-F

10GBASE DWDM SFP+ 100GHz 80km SMF Transceiver Finisar FTLX3811M3xx Compatible

F-tone DWDM-XFP10G-80 Small Form Factor 10Gb/s (XFP) transceivers comply with the current XFP Multi-Source Agreement (MSA) Specification1. This transceiver offers the same function with Finisar FTLX3811M3xx and it is fully compatible with Finisar devices. This module is designed for single mode fiber and operates at a nominal DWDM wavelength from 1528.77nm to 1563.86nm as specified by the ITU-T. It is designed to deploy in the DWDM networking equipment in metropolitan access and core networks. They exceed the requirements for DWDM 10Gb/s SONET/SDH interfaces per ITU-T G.698.1 S-D100S1-2D, and support DWDM 10-Gigabit Ethernet, 10-Gigabit Fiber Channel, and 10-Gigabit Ethernet. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA.

Key Features

  • Supports 9.95Gb/s to 11.1Gb/s bit Rates
  • High Quality with ISO9001, TUV, CE, FCC, UL and RoHS certificates
  • Auxiliary 1 Monitoring Laser Temperature
  • Auxiliary 2 Monitoring 5V Supply
  • Temperature-Stabilized DWDM EML Transmitter
  • Maximum Link Length of 80km
  • Hot-Pluggable XFP Footprint
  • 100GHz ITU Grid, C Band
  • Duplex LC Connector
  • Built-in Digital Diagnostic Functions
  • Power Dissipation < 3.5W
  • Average Output Power:0~5dBm
  • Receiver Sensitivity:-24dBm
  • Temperature range: 0°C to 70°C

Applications

  • 10GBASE-ER/EW Ethernet
  • 10G Fiber Channel
  • SONET OC-192/STM-64

Ordering Information

Part No. Data Rate (Gbps) Frequency
(GHz)		 Channel/
Wavelength (nm)		 TX Power (dBm) Re Sens. (dBm) Transmission Distance Fiber Type Connector Type Temp. Range Digital Diagnostics
DXFP-10GXX-40 10 100GHz CH17~CH61
(1563.86~1528.77)		 -1~4 ﹤-15 40km SMF LC 0~70℃ Yes
DXFP-10GXX-40A 10 100GHz CH17~CH61
(1563.86~1528.77)		 -1~4 ﹤-15 40km SMF LC 0~70℃ Yes
DXFP-10GXX-40B 10 100GHz CH17~CH61
(1563.86~1528.77)		 -1~4 ﹤-15 40km SMF LC 0~70℃ Yes
DXFP-10GXX-80 10 100GHz CH17~CH61
(1563.86~1528.77)		 0~5 ﹤-24 80km SMF LC 0~70℃ Yes
DXFP-8GXX-80 8.5 100GHz CH17~CH61 (1563.86~1528.77) -1~4 ﹤-25 80km SMF LC 0~70℃ Yes
DXFP-10GXX-120 10 100GHz CH17~CH61
(1563.86~1528.77)		 120km SMF LC 0~70℃ Yes
DXFP-10GHXXX-40 10 50GHz CH17~CH61 (1563.86~1528.38) -1~2 ﹤-15 40km SMF LC 0~70℃ Yes
DXFP-10GHXXX-80 10 50GHz CH17~CH61 (1563.86~1528.38) -1~2 ﹤-24 80km SMF LC 0~70℃ Yes

Notes

  • XX means DWDM ITU Channel (CH17 = 1563.86nm, CH18 =1563.05nm, CH19 = 1562.23nm, CH20 = 1561.42nm, etc.)
  • F-tone also provide other DWDM XFP transceivers with different transmission distances, like 120km

Packaging

  • Antistatic bag
  • Packed on pallets in a box(Default Customer Options)
  • Specific Labels as Request
  • Seperate white Box for each transceiver

OEM and ODM

Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, F-tone provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for F-tone in the world.

  • OEM/ODM order is available
  • We can supply DWDM-XFP10G-80 according to your requirements, and design DWDM-XFP10G-80 label and packaging for your company. We welcome any inquiry for customized 10G DWDM XFP optical transceiver.

Order Procedure

Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
a. Email ([email protected]) us a rough sketch to a detailed drawing.
b. Our engineer will review the project and provide a quotation within 24 hours.
c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.

Shipment

International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.

Save Cost By Buying 10G DWDM XFP From Original Manufacturer F-tone Directly.

F-tone is an professional manufacturer & supplier of DWDM XFP transceivers. All of our DWDM XFP transceivers are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee DWDM XFP transceivers to work in your system and all of our DWDM XFP transceivers come with a lifetime advance replacement warranty. If you have questions about DWDM XFP optics, please feel free to contact us at [email protected].

All the 10GB DWDM XFP 80km 100GHz Wavelengths that we can offer refer to the following table:

Channel Part No. Frequency (GHz) Center Wavelength (nm)
17 DXFP-10G17-80 191.7 1563.86
18 DXFP-10G18-80 191.8 1563.05
19 DXFP-10G19-80 191.9 1562.23
20 DXFP-10G20-80 192 1561.41
21 DXFP-10G21-80 192.1 1560.61
22 DXFP-10G22-80 192.2 1559.79
23 DXFP-10G23-80 192.3 1558.98
24 DXFP-10G24-80 192.4 1558.17
25 DXFP-10G25-80 192.5 1557.36
26 DXFP-10G26-80 192.6 1556.55
27 DXFP-10G27-80 192.7 1555.75
28 DXFP-10G28-80 192.8 1554.94
29 DXFP-10G29-80 192.9 1554.13
30 DXFP-10G30-80 193 1553.33
31 DXFP-10G31-80 193.1 1552.52
32 DXFP-10G32-80 193.2 1551.72
33 DXFP-10G33-80 193.3 1550.92
34 DXFP-10G34-80 193.4 1550.12
35 DXFP-10G35-80 193.5 1549.32
36 DXFP-10G36-80 193.6 1548.51
37 DXFP-10G37-80 193.7 1547.72
38 DXFP-10G38-80 193.8 1546.92
39 DXFP-10G39-80 193.9 1546.12
40 DXFP-10G40-80 194 1545.32
41 DXFP-10G41-80 194.1 1544.53
42 DXFP-10G42-80 194.2 1543.73
43 DXFP-10G43-80 194.3 1542.94
44 DXFP-10G44-80 194.4 1542.14
45 DXFP-10G45-80 194.5 1541.35
46 DXFP-10G46-80 194.6 1540.56
47 DXFP-10G47-80 194.7 1539.77
48 DXFP-10G48-80 194.8 1538.98
49 DXFP-10G49-80 194.9 1538.19
50 DXFP-10G50-80 195 1537.4
51 DXFP-10G51-80 195.1 1536.61
52 DXFP-10G52-80 195.2 1535.82
53 DXFP-10G53-80 195.3 1535.04
54 DXFP-10G54-80 195.4 1534.25
55 DXFP-10G55-80 195.5 1533.47
56 DXFP-10G56-80 195.6 1532.68
57 DXFP-10G57-80 195.7 1531.9
58 DXFP-10G58-80 195.8 1531.12
59 DXFP-10G59-80 195.9 1530.33
60 DXFP-10G60-80 196 1529.55
61 DXFP-10G61-80 196.1 1528.77

Prices and specifications are subject to change without notice. F-tone.Com Transceiver is not responsible for typographical or photographic errors.


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
