EPON OLT SFP 1490nmTx/1310nmRx 1.25GTx/1.25GRx 20km DDM Transceivers

EPON OLT SFP 1490nmTx/1310nmRx 1.25GTx/1.25GRx 20km DDM Transceivers

Afficher tous les détails

Part Number: ESFP-43-20

1.25G EPON Transceiver (SMF, 1490nmTx/1310nmRx, 20km, SC)

Product Details

Part Number ESFP-43-20 Vendor Name F-tone
Data Rate 1.25G Fiber Mode Single Mode Fiber (SMF)
Types of Interface SC Types of Laser DFB-LD
Operating Temperature Standard 0~70C Operating Humidity 0%~90%RH (no condensing)
Transmission distance 20km Modes of Communications Simplex
Wavelength 1490nm/1310nm Receiver Sensitivity <-28dBm
Extinction Ratio >9dB Saturated Optical Power 6dBm
Form Factor GEPON SFP ONU/OLT Power Consumption <1.5W
Hot Pluggable Times 200 Average Output Power 2~7dBm

Quality Control System:

Our Test Assured ProgramTake a look at our optics test program and see what truly sets us apart.

Learn More

Packaging & Labeling

This easy to handle and well-protected transceiver package has been labelled and marked to default F-tone standards. Customized label or package solutions are available on request.

OEM & Customs

Partnering with a variety of world class OEM manufacturers for over 8 years, F-tone is able to provide customized high-quality and cost-effective solutions for all needs and specifications, including optical design, mechanical design, Printed Circuit Board (PCB) layout and electrical design, software & firmware design, integrated assembly, specific labels, etc. With surging sales and favorable customer feedback, F-tone has been expanding rapidly across the world and is becoming the leading provider of the optical communication industry. If you are interested in our products, please feel free to contact us at [email protected] .

Shipment

F-tone can ship via FedEx, DHL, UPS, TNT, EMS or a customer-arranged carrier. Items are often shipped the same day (some transceivers can be out the door in 20 minutes). If we have no stock in any of our global warehouses, the shipment will be delayed for 1-2 days. DHL will take 2-4 business days for delivery and FedEx only needs 1-3 business days. For Spain, Italy, Brazil and certain other countries, items will take longer to arrive due to the customs clearance period.


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
