F-tone S1213-15 622Mbps OC-12/STM-4 SDH/SONET 1310nm Single-mode Dual LC 15km SFP Transceiver Module

F-tone S1213-15 622Mbps OC-12/STM-4 SDH/SONET 1310nm Single-mode Dual LC 15km SFP Transceiver Module

Afficher tous les détails

Features

  • Hot-Pluggable SFP Footprint LC Optical Transceiver
  • Small Form-Factor Pluggable (SFP) MSA compatible
  • Compliant with SONET OC-12 IR-1 / SDH STM-4(S-4.1)
  • 1310 nm Transmitter, single-mode fiber
  • 0 to 15000 m Transmission
  • AC/AC Coupling according to MSA
  • Single +3.3 V Power Supply
  • RoHS Compliant

Specifications

Parameter Value
Part Number S1213-15
Device Type OC12 SFP
Package SFP
Data Rate 622Mbps
Wavelength 1310nm
Distance/Power Budget 15km
Optical Components LD FP
Optical Components PD PIN
Output Power -15~-8dBm
Receiver Sensitivity -30dBm
Power Supply Voltage 3.3V
Connector Dual LC
Fiber Type SMF
Operating Temperature 0~70/ -10~80/ -40~85 °C
DDMI With/ Without
Application FE/ SDH/ SONET/ FTTx
Compatibility All Brands

Labeling Options

  • F-tone Labels (Default)
  • Generic Labels
  • Customised Labels
  • No Labels

Email us your design if you choose customised labels.

F-tone is the original manufacturer of OC12 SFP S1213-15 - 622Mbps OC-12/STM-4 SDH/SONET 1310nm Single-mode Dual LC 15km SFP Transceiver Module. We have ready stock for S1213-15 and can ship it out in two business days. We guarantee the S1213-15 transceiver module to work in your system and all of our S1213-15 transceiver modules come with a lifetime warranty.

The S1213-15 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The S1213-15 must be operated within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Tout afficher

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Tout afficher

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
