F-tone S2G85-05 - 2.125Gbps 2X/1X Fiber Channel Dual LC 850nm Multi-mode 300m SFP Optical Transceiver Module

F-tone S2G85-05 - 2.125Gbps 2X/1X Fiber Channel Dual LC 850nm Multi-mode 300m SFP Optical Transceiver Module

Afficher tous les détails

Description

Features

  • Hot-Pluggable SFP Footprint LC Optical Transceiver
  • Small Form-Factor Pluggable (SFP) MSA compatible
  • Compliant with Fiber Channel FC-PH-2 for 200-M5-SN-1 and 200-M6-SN-1
  • Compliant with IEEE 802.3z Gigabit Ethernet 1000BASE-SX
  • Link Distance at 2.125 Gbd
  • 150 m links with 62.5/125 mm MMF Cables
  • 300 m links with 50/125 mmMMF Cables
  • Link Distance at 1.026 Gbd
  • 300 m links with 62.5/125 mm MMF Cables
  • 500 m links with 50/125 mmMMF Cables
  • AC/AC Coupling according to MSA
  • Single +3.3 V Power Supply
  • RoHS Compliant
  • Class 1 Laser International Safety Standard IEC-60825 Compliant

Specifications

Parameter Value
Part Number F-tone S2G85-05
Device Type FC SFP
Package SFP
Data Rate 2.125/1.0625Gbps
Wavelength 850nm
Distance/Power Budget 300/500m
Optical Components
  • LD: VCSEL
  • PD: PIN
Output Power -9~0dBm
Receiver Sensitivity -17/-18dBm
Power Supply Voltage 3.3V
Connector Dual LC
Fiber Type MMF
Operating Temperature 0~70/ -10~80/ -40~85 °C
DDMI With/ Without
Application Multi-rate FC
Compatiblity All Brands

F-tone is the original manufacturer of FC SFP F-tone S2G85-05 - 2.125Gbps 2X/1X Fiber Channel Dual LC 850nm Multi-mode 300m SFP Optical Transceiver Module. We have ready stock for F-tone S2G85-05 and can ship it out in two business days. We guarantee the F-tone S2G85-05 transceiver module to work in your system and all of our F-tone S2G85-05 transceiver modules come with a lifetime warranty.

The F-tone S2G85-05 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The F-tone S2G85-05 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

  • F-tone Labels (Default)
  • Generic Labels
  • Customised Labels
  • No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
