6 Fibers, 3 Ports Fiber Adapter Panel with 3 SC Duplex 10G OM1 Multimode Adapters (Electric Ivory), Zirconia Ceramic

6 Fibers, 3 Ports Fiber Adapter Panel with 3 SC Duplex 10G OM1 Multimode Adapters (Electric Ivory), Zirconia Ceramic

Afficher tous les détails

Part Number: FHD-FAP3SCDPOM1

3-Position SC Fiber Adapter Panel, Zirconia Ceramic Sleeve, Rack and Wall Mount Enclosures

No.of Adapter/Port 3 Fiber Count 6
Adapter Type SC Duplex(Electric Ivory) Fiber Mode OM1
Material of Sleeve Zirconia Ceramic Plate C.R.S POWDER COATED
FAP Orientation Horizontal Dimensions(mm) 109.1*35*11.4(L*W*H)
RoHS Compliancy Status Compliant Application Rack and Wall Mount Enclosures

Key Features and Benefits

Provides a complete system solution for connectivityMeet or exceed TIA/EIA-568-C.3 requirementsAllows for the industry's highest patch field density and fiber countsAssures flexibility and ease of network deployment and moves, adds, and changes

Drawing and Dimension(mm)

F-tone.COM Three Port SC Series Fiber Adapter Panels

F-tone FAPS ADAPTER COLOR FIBER TYPE DUPLEX & SIMPLEX SPLIT SLEEVERS
FHD-FAP3SCADZSMF Green OS2 DUPLEX Zirconia Ceramic
FHD-FAP3SCDZSMF Electric Ivory OS2 DUPLEX Zirconia Ceramic
FHD-FAP3SCDPSMF Blue OS2 DUPLEX Zirconia Ceramic
FHD-FAP3SCADZSMF Electric Ivory OS2 DUPLEX Zirconia Ceramic
FHD-FAP3SCDPOM1 Electric Ivory OM1 DUPLEX Zirconia Ceramic
FHD-FAP3SCDPOM1-BX Electric Ivory OM1 DUPLEX Zirconia Ceramic
FHD-FAP3SCDP1GMM Electric Ivory OM1/OM2 DUPLEX Zirconia Ceramic
FHD-FAP3SCDZ10GMM Auqa OM3/OM4 DUPLEX Zirconia Ceramic
FHD-FAP3SCDZOM4 Auqa OM4 DUPLEX Zirconia Ceramic
FHD-FAP3SCDPOM4 Auqa OM4 DUPLEX Zirconia Ceramic

Packaging Detais


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
