12 Fibers 6x SC/UPC Duplex OM4 Multimode Fiber Adapter Cassette with Pigtails

12 Fibers 6x SC/UPC Duplex OM4 Multimode Fiber Adapter Cassette with Pigtails

Afficher tous les détails

Part Number: FT-FAC12F-SCD-OM4

Fiber Adapter Cassette 12 Fibers 6x SC/APC Duplex OM4 Multimode

The fiber adapter cassette modulesaccommodates and protects up to 48 fiber splices, supporting efficient cable organization and bend radius control to enhance cabling reliability and maintainability. The module can be directly installed into adapter cassette enclosures, eliminating the need for additional splice trays and streamlining deployment while improving space utilization.

Pre-loaded with pigtails, the cassette integrates heat shrink splice sleeves, splice holders, and fiber slack management features. It supports LC, SC, and MTP interfaces with UPC or APC polish types, meeting diverse cabling requirements. Ideal for high-density fiber cabling in WANs, data centers, campus networks, government facilities, and central offices.

Item Spotlights

● Integrated Splice Holder Enables Easy Maintenance of Individual Spliced Fibers and Scalable Expansion Without Impacting Adjacent Fibers

● Tool-less Push-lock Rivets Support One-handed Installation and Removal, Simplifying Operation and Improving On-site Efficiency

● Interface Color-coding Follows the TIA/EIA-568.3-D Standard, Making it Easy to Identify Fiber Types and Connector Polish

● Compatible with F-tone Adapter Cassette Enclosures, Supporting Front Installation and Independent Module Operation Without Disturbing Adjacent Cassettes

● Pre-terminated SC Adapters Help Save Time and Ensure Reliable Connections in High-density Data Centers, Enabling Easy On-site Assembly

Specifications

Fiber Count 12 Fibers Fiber Mode OM4 50/125μm
Front Connector Type SC UPC Duplex (Aqua) Number of LC Port 6 Ports
Insertion Loss ≤0.3dB Return Loss ≥20dB
Material of Splice Tray ABS Housing Type Cassette
Material of Sleeve Zirconia Ceramic Material of Cassette Body Aluminium (AL5052)
Included 0.9mm OD, 70cm Pigtails, Heat Shrink Splice Sleeves, Splice Holders, Cable Tie Dimensions (HxWxD) 1.38''x 4.29''x 6.29'' (35x 109x 160mm)
Operating Temperature -10 to 60℃ Storage Temperature -10 to 60℃
Standard RoHS Compliant Application Matching for F-tone Adapter Enclosures


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
