SC/APC FASTConnect Singlemode 900µm Strain Relief Pack of 6

SC/APC FASTConnect Singlemode 900µm Strain Relief Pack of 6

Afficher tous les détails

Part Number: FT-FAST-SC-SMAU-6

AFL FastConnect - SC/APC Singlemode 900um FAST-SC-SMAU-6

FASTConnect® field-installable connectors are factory pre-polished connectors that completely eliminate the need for hand polishing in the field. Proven mechanical splice technology ensuring precision fiber alignment, a factory pre-cleaved fiber stub and a proprietary index-matching gel combine to offer an immediate low loss termination to either single-mode or multimode optical fibers.

FASTConnect® connectors are compatible with 250 µm and 900 µm optical fibers, as well as 900 µm, 2 mm and 3 mm cordage. All primary fiber types are supported, and each connector is color coded per industry-standard requirements to aide in identification during and after installation. A factory-installed wedge clip (included with each connector) is removed and discarded upon completion of the termination. Incorporated into this device is an innovative, translucent wedge enabling the use of a common VFI to provide a “pass/fail” signal once physical contact is achieved.

Features

● Pre-stubbed, factory-polished ferrule

● No epoxy required

● Precision mechanical alignment ensures low loss

● Fiber can be reseated

● 900uum boot provided with each connector with separate boot kits available for 2.0 and 3.0mm diameter style cables

● VFI can be used to confirm fiber is installed properly

Applications

● Premise environments

● Connections at the desk for LAN environments

● Patch panels

● Direct equipment termination

● Fiber to the Subscriber (FTTx) applications

● Repair and replacement requirements

● Equipment test leads

Specifications

Parameter Value
Fiber Type Singlemode and Multimode
Insertion Loss (Max) SM APC 0.6dB, SM UPC 0.5dB, MM 0.5dB
Insertion Loss (Typical) SM APC 0.3dB, SM UPC 0.2dB, MM 0.1dB
Return Loss (Typical) SM APC ≤-55dB, UPC ≤-50dB, MM ≤-25dB
Polishing Type PC, UPC and APC
Operating Temperature -40°C to +75°C


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
