1U High Density Rack Mount Blank Enclosure Unloaded, Detachable Panel and Bar for 4 HD Cassettes/Panels

1U High Density Rack Mount Blank Enclosure Unloaded, Detachable Panel and Bar for 4 HD Cassettes/Panels

Afficher tous les détails

Part Number: FT-FHD-1U4P-RMD

1U High Density Rack Mount Blank Enclosure Unloaded, Detachable Panel and Bar, Holds 4 HD Cassettes/Panels

This 1U rack mount enclosure for 19" EIA racks accepts up to four HD series fiber adapter panels, offering a flexible and modular system for fiber management and patching. Its snap-in/pull-out design simplifies installation, moves, adds, and changes. The detachable design allows for separation into patch panels, plastic D-rings, lacer panels, and lacer bars. The steel lacer panel features four pass-through holes for easy HD fiber adapter panel installation. This horizontal cable management panel protects cables from snags and damage.

The High Density Series provides versatile solutions in various sizes (1U/2U/4U) and styles for backbones, data centers, and enterprise applications.

Features

● Detachable Front and Rear Cable Managers, Used Separately for Cabling

● 360° Rotatable D-rings Bring Maximum Routing Flexibility

● Modular Design Mounts Up to Four HD Panels

● Up to 144 Fibers (LC) or 1,152 Fibers (MTP®-24)

● Side and Rear Cable Entry Provide Several Options to Route Cable

● Space Saving 1U Design, Mount to Standard EIA 19" Rack Rails

● Hybrid Type for Both Fiber and Copper Solution

Specifications

Number of Rack Spaces 1U Fiber Count Up to 144 Fibers (LC) or 1,152 Fibers (MTP®-24)
Product Type Blank Enclosure Shielding Type Unshielded
Number of Slots 4 Color Black
Material Steel, Powder-coated Black D-rings Material PC, UL 94V-2
Dimensions (HxWxD) 1.73''x19.00''x8.93"(44.0x482.6x227.0mm) Installation Standard EIA 19" Rack Rails
Loaded Unloaded Application Accepts HD Adapter Panels


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
