FT2100GK GPON ONT/SFU with 1-GPON Port and 1*10/100/1000M Port

FT2100GK GPON ONT/SFU with 1-GPON Port and 1*10/100/1000M Port

Afficher tous les détails

Part Number: FT-G2100GK

GPON ONT/SFU with 1-GPON Port and 1*10/100/1000M Port


GPON SFU is designed for FTTH and networking service providers. FT2100GK is developed by F-tone based on the Gigabit GPON technology, has a high cost performance. It is high stability and easy to maintain, has multi-service QoS quality guarantee. And It is fully compliant with technical regulations such as ITU-T G.984.x and technical requirement of GPON Equipment (V2.1 and above version) from China Telecom, China Unicom.

Application Chart



Features

  • Single-port SFU home terminal devices
  • Main service: 1GE
  • Plug and play, integrate auto detection, auto configuration and auto firmware upgrading
  • Integrate OMCI and TR-069 remote configuration and maintenance
  • Compatible with Huawei, ZTE and Fiberhome OLT
  • Support diagnostic monitoring and remote disabling of fiber optical
  • Support alarm detection reporting function
  • Support Performance Statistics function
  • Support OLT control ONU PON port energy-saving mechanism

Data Service Functions

  • Full speed 1G non-blocking switching
  • 2048 MAC address table
  • Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc
  • Support auto polarity detection of Ethernet ports (AUTO MDIX)
  • Integrated IEEE802.1p QoS with four level priority queues

Specifications:

Technical items Descriptions
Fiber port 1 GPON interface, SC single-mode/single-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength Tx 1310nm, Rx 1490nm
Fiber interface SC/PC
RX sensitivity <-28dBm （1490nm）
WLAN IEEE802.11b/g/n，300Mbps, a built-in antenna
LAN 1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
Throughput Throughput can reach 900Mbps or more
POTS 1*FXS, RJ11 connector
DC power 12V 1A, external AC-DC power adapter
Button Reset, power
Power ≤8W
Operation Working temperature: -5〜+55℃ working humidity:10-90％(non-condensation)
Storage Storage temperature: -30℃〜+60℃ storage humidity: 10-90％(non-condensation)
Dimension 130*105*30mm(length*width*height)
Net weight ≤0.2Kg

Specifications:

Technical items Descriptions
Fiber port 1 GPON interface, SC single-mode/single-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength Tx 1310nm, Rx 1490nm
Fiber interface SC/PC
RX sensitivity <-28dBm （1490nm）
WLAN IEEE802.11b/g/n，300Mbps, a built-in antenna
LAN 1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
Throughput Throughput can reach 900Mbps or more
POTS 1*FXS, RJ11 connector
DC power 12V 1A, external AC-DC power adapter
Button Reset, power
Power ≤8W
Operation Working temperature: -5〜+55℃ working humidity:10-90％(non-condensation)
Storage Storage temperature: -30℃〜+60℃ storage humidity: 10-90％(non-condensation)
Dimension 130*105*30mm(length*width*height)
Net weight ≤0.2Kg



This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
