FT2210K GPON ONT/HGU with 1-GPON Port, 1*10/100/1000M +1*10/100M+1*VOIP Ports

FT2210K GPON ONT/HGU with 1-GPON Port, 1*10/100/1000M +1*10/100M+1*VOIP Ports

Afficher tous les détails

Part Number: FT-G2210k

GPON ONT/HGU with 1-GPON Port, 1*10/100/1000M +1*10/100M+1*VOIP Ports


GPON ONT/HGU is designed for FTTH and networking service providers. F-tone FT2210K is developed based on the Gigabit GPON technology which supports the 802.11n wireless networking technology(T/R), supports 2 layer, 3 layer or more layer VoIP. It is of high stability and easy to maintain, and has multi-service QoS quality guarantee. And It is fully compliant with technical regulations such as ITU-T G.984.x and technical requirement of GPON Equipment (V2.1 and above version) from China Telecom, China Unicom.

Application Chart


Key Features

  • Main service: 1GE+1FE+1VOIP
  • Plug and play, integrate auto detection, auto configuration and auto firmware upgrading
  • Integrate OMCI and TR-069 remote configuration and maintenance
  • Support flexible QinQ VLAN,DHCP server/relay and IGMP/MLD multicast monitoring function
  • Support diagnostic monitoring and remote disabling of fiber optical
  • Compatible with Huawei,ZTE and Fiberhome OLT
  • Support NAT and firewall function
  • Support IPv4 and IPv6 dual stack
  • POTS integrated circuit test complies GR-909
  • WAN support networking bridge, router and bridge/router mixed mode

Specifications:

Technical items Descriptions
Fiber port 1 GPON interface, SC single-mode/single-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength Tx 1310nm, Rx 1490nm
Fiber interface SC/PC
RX sensitivity <-28dBm （1490nm）
WLAN IEEE802.11b/g/n，300Mbps, a built-in antenna
LAN 1*10/100/1000Mbps+1*10/100Mbp adaptive Ethernet ports, full/half duplex, RJ45 interface
Throughput Throughput can reach 900Mbps or more
POTS 1*FXS, RJ11 connector
DC power 12V 1.5A, external AC-DC power adapter
Button Reset, power
Power ≤10W
Operation Working temperature: -5~+55℃ working humidity:10~90％(non-condensation)
Storage Storage temperature: -30℃〜+60℃ storage humidity: 10~90％(non-condensation)
Dimension 185*145*50mm(length*width*height)
Net weight ≤0.3Kg

Data Service Functions

  • Full speed 1G non-blocking switching
  • 2048 MAC address table
  • 16 LAN
  • Support VLAN QinQ, transparent, tag, translation, trunk, etc.
  • Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc
  • Support auto polarity detection of Ethernet ports (AUTO MDIX)
  • Integrated IEEE802.1p QoS with four level priority queues
  • Support IPv4 IGMP snooping and IPv6 MLD snooping.
  • Support bridging, router and bridging/router mixed mode.

POTS Service Function

  • support SIP voice protocol
  • support H.248 voice protocol
  • SIP protocol: ISP provide the port number of the main SIP proxy server and terminalVOIP Value range is 1-65535, system default value is 5060
  • H.248 protocol: ISP provide port number of the spare MGC server and VOIP terminal Value range is 1~65535, system default value is 2944
  • Port ringing current voltage: 50±10VAC，30±10H
  • Port type POTS(VOIP)
  • Support G.711 A-Law/u-Law,G729A/B,G.723.1-5.3/6.3,G.726.etc.voice coding/compressed technology
  • Support auto switch in main interface and standby interface by the software

Specifications:

Technical items Descriptions
Fiber port 1 GPON interface, SC single-mode/single-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength Tx 1310nm, Rx 1490nm
Fiber interface SC/PC
RX sensitivity <-28dBm （1490nm）
WLAN IEEE802.11b/g/n，300Mbps, a built-in antenna
LAN 1*10/100/1000Mbps+1*10/100Mbp adaptive Ethernet ports, full/half duplex, RJ45 interface
Throughput Throughput can reach 900Mbps or more
POTS 1*FXS, RJ11 connector
DC power 12V 1.5A, external AC-DC power adapter
Button Reset, power
Power ≤10W
Operation Working temperature: -5~+55℃ working humidity:10~90％(non-condensation)
Storage Storage temperature: -30℃〜+60℃ storage humidity: 10~90％(non-condensation)
Dimension 185*145*50mm(length*width*height)
Net weight ≤0.3Kg



This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
