8 Ports SFP to 1 Port XFP FT-P-OTP800-TMUX(10G) Optical Muxponder Service Card

Part Number: FT-P-OTP800-TMUX(10G)

FT-P-OTP800-TMUX(10G) 8 Ports SFP to 1 Port XFP Optical Muxponder Service Card

Wavelength Conversion of 8 Ports 1.25G Data to 1 Port 10G Data Optical Muxponder Service Card

FT-P-OTP800-TMUX(10G) is a kind of Muxponder service card developed by F-tone. It can transparently gather 8*1.25G data to 1*10G data, which can tremendously save room for DWDM modules and fiber resources, strengthen stability, as well as save cost.

Key Features

• It provides 8 standard SFP slots and 1 XFP slot
• 8 GE ports at the client side are isolated from each other
• It supports statistics on error packet of each port
• It supports loopback setting of the client side and the line side
• It supports SNMP network management
• It adopts time-division multiplexing technology
• GE port sources are available for option

Front Panel Appearance

Valid Slots

The FT-OEO800-MUX(10G) board occupies one slot.
Valid Slots in the Sub-racks
a. In the FT-P-OTP800-2S rack mount, there is no slot designed for SC control board.
b. In the FT-P-OTP800-4S rack mount, the valid slot of the board is SLOT1 only.
c. In the FT-P-OTP800-11S rack mount, the valid slot of the board is SLOT1 only.

Application

• MUX (10G) achieves multiplexing of eight Gigabit Ethernet service to a 10G link, thereby reduces wavelength requirements of the WDM system. There are 8 pluggable SFP ports at the client side and1 pluggable XFP port at the line side.

Working Principle and Signal Flow

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
