S5720 Series Layer3 Managed Ethernet Switch

S5720 Series Layer3 Managed Ethernet Switch

Afficher tous les détails

Part Number: FT-S5720-X

Layer3 S5720 Series Managed Ethernet Switch

S5720 series Layer 3 managed stackable Ethernet switches supports up to 24 port 2.5G Ethernet ports and 10G SFP+ uplink ports. In addition to complete layer 2 functions such as QoS, VLAN, IGMP Snooping/GMRP, Port Trunking, SNMP V1/V2/V3, RSTP/STP/ERPS, etc. It also supports layer 3 functions such as static routing, RIP V1/V2, OSPF, VRRP, etc. protocol. Optional AC+DC power supply, wide temperature design, strong anti-electromagnetic interference capability, S5710 is good solution for enterprise or telecom networks.

Features

● 10/100/1000M/2.5G Ethernet port

● 10G SFP+ uplink port

● 249Gbps switching capacity

● 802.3az energy saving

● Single AC power supply

● Layer3 static & dynamic routing

● Support stacking function

Application Solution

Specifications

Attribute S5720-24M6X S5720-24MP6X
Ethernet Port 24*100/1000M/2.5G Base-T RJ45 24*10/100/1000M/2.5G Base-T POE
Optic Port 6*1000M Base-X SFP/10GE SFP+
Chipset Realtek 9313
Switching Capacity 240Gbps
Forwarding Rate 178.57Mpps
MAC 32K
Multicast 4K
Route 12K
PoE Port / 1~24 port (IEEE 802.3af/at)
PoE Budget / 415W
RAM/Flash RAM: 512MB; Flash: 32MB
Power Supply AC: 100～240V 47/63Hz；
DC: -40V～-60V		 AC: 100～240V 47/63Hz
Power Consumption ≤39W ≤450W
Dimension (L*W*H) 440*260*44mm 440*260*44mm
Environment Temperature Working Temperature: -10℃~ 50℃
Storage Temperature: -40℃~ 70℃
Relative Humidity: 5%~95%, non-condensing
Software Features
VLAN MAC and protocol VLAN, QinQ and flexible QinQ
Ring Protoco STP/RSTP/MSTP, ERPS
PoE Control Support
Port Aggregation Static link aggregation Support dynamic LACP
Mirroring Support
ACL Support standard and extended ACL
QoS 802.1P, DSCP priority
Safety IEEE 802.1X authentication, Radius&TACACS+ authentication
Layer3 Routing Static/dynamic routing, RIP/OSPF/BGP/IS-IS
Management CLI、Telnet、WEB、SNMP V1/V2/V3、SSH

Product Features

Stability QoS Capabilities
● Linux operating system

● IPv4/IPv6 dual protocol stack platform

● STP/RSTP/MSTP/ERPS/LACP etc.		 ● Support port speed and flow speed limit

● Support Service flow and QoS flow control

● Support SP/WRR/SP+WRR

● Support port-based and service flow-basedmirroring functions
Safety Mechanism Routing Protocol
● Support ACL security filtering mechanism based on MAC, IP, L4 port

● Support Anti-ARP & User Blocking function

● Support DHCP attack automatic protection

● Support DDOS and virus attack protection

● Support DHCP/IP/802.1X etc.

● Support BFD, FlexLink, LACP and ERRP etc.

● Support Remote Loop Detection function

● Support CFM、EFM

● Support Tacacs+, Radius, and Local user authentication		 ● Support Static Route

● Support RIP, OSPF,BGP, ISIS

● Support IPV4/IPV6 dual protocol stack

● Support RIPng、OSPFv3
Multi-service Capabilities Network Management
● Support DHCP Server and DHCP Relay

● Support L2-Tunnel

● Support Ethernet OAM protocol (CFM、EFM)		 ● Support CLI based on RS232 serial port, Telnet and SSHv2

● Support RFC1213 SNMP

● Support WEB-based configure operation

● Support SNMP V1/V2/V3

● Support FTP & TFTP remote upgrade and download


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
