ST-4103x Optical Talk Set

ST-4103x Optical Talk Set

Afficher tous les détails

Part Number: FT-ST-4103x

ST-4103 Optical Talk Set

ST-4103 Optical Talk Set is an intelligent and efficient instrument that combines in one set the functions of both a digital optical phone and a stabilized light source. It is widely used in operations of installation, optical testing, maintenance and fiber attenuation value testing in data network, CATV and Telecommunication network. The ST-4103 Talk Set can carry out full-duplex communication with high quality connection and not be affected by distance.

Key Features

  • Full-duplex digital communication with high quality conversation connection and low background noise
  • Together with Optical Clip-on Coupler, enables on line communications available
  • Combining functions of both a digital optical phone call and a stabilized light source
  • Large LCD display with backlight.

Applications

  • Maintenance in Telecom
  • Maintenance CATV
  • Test Lab of optical fibers
  • Other Fiber Optic Measurements

Specifications

Type ST-4103
Wavelength(nm) 1310/1550
Emitter Type FP-LD
Transmission Distance ≤ 80km
Dynamic Range 40dB
Output Power -5~-7dBm(9/125um), CW or 2KHz, 1KHz, 270Hz Modulation
Output Stabvlity ± 0.1dB/± 0.25dB(1/8hrs) CW
Power Supply Rechargeable Battery + Power Supply Adaptor
Battery Operating Time 5 hours
Optical Connector FC/PC
Operating Temperatrue(°C) -10 ~ +60
Storage Temperatrue(°C) -25 ~ +70
Dimension(mm) 215X115X55

Note: This price is for one pair of it.

Fiber optic talk set carry full-duplex communication with high quality voice connection without being affected by distance, it is widely used in operations of fiber optic installation, testing and maintenance works. If you need this ST-4103 Optical Talk Set in a large quantity, welcome to contact us. We will give you a special discount.


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
