6 Entries S019 Series Mechanical Seal Type Vertical/Dome Fiber Optic Splice Closures to 105 Fibers

6 Entries S019 Series Mechanical Seal Type Vertical/Dome Fiber Optic Splice Closures to 105 Fibers

Afficher tous les détails

Part Number: FT019-3IO-105

FT-S019 Series 6 Entries Vertical/Dome Fiber Optic Splice Closure Max. Capability up to 105 Fibers

Vertical (Dome) fiber optic splice closures are made of excellent engineering plastics. F-tone.COM supply different ports types, fittings and different fiber optic core numbers for vertical/dome fiber optic splice closures. The main application for vertical fiber optic splice closure is in CATV, telecommunications and fiber optic networks. They are suitable for protecting optical fiber splices in straight through and branching applications, and can be used in aerial, duct and direct buried fiber optic cable projects.

Key Features

  • Easy to install and easy to re-enter Cable entry/exit ports
  • High mechanical performance
  • Can be used in through, branch or mid span splice locations
  • Excellent sealing performance
  • Endure harsh conditions such as vibration, impact, tensile cable distortion and strong temperature changes
  • Does not require special tools, easy to install and open the duplicate.
  • The use of reusable components to open seal in order to ensure a good airtight waterproof performance.
  • Come with related fiber optic trays and splice protection sleeves
  • The scope of application : aerial, direct-buried, wall-mounting, duct-mounting

Main Technical Parameters

  • The application of temperature : -40℃～65℃
  • Atmospheric pressure: 70～106KPa
  • Resist pull: ＞1000N
  • Insulation resistance: ＞2×104MΩ
  • Resist pressure: ＞2000N/10cm2pressure,time 1 min
  • Dielectric strength: 15KV (DC)/1 min spark-over and no flying arc.

Specifications

  • No. of Cable Inlet/Outlet: 3 in,3 out
  • Number of Fibers, Bunchy: 105
  • Max capacity of fiber: 147（bunch）
  • Sealing Way: Mechanical Seal
  • Capacity of splice tray:16/21(bunch) ,48(ribbon)
  • Max qty of splice tray: 6
  • Outer carton dimension(mm): 650*620*460/4pcs, Weight: 38kg/4pcs

Specification

Dimension 610*185*140/1pcs
Cable diameter(mm) 7~28
Cable ports 3 in,3 out
Capacity of splice tray 16/21(bunch) ,48(ribbon)
Max qty of splice tray 6
Max capacity 147(bunch)
Sealing structure Screw thread mechanical sealing
Sealingmaterial Silicon gum material
Outer carton dimension(mm) 650*620*460/4pcs
Outer carton volume (m3) 0.186
Outer carton weight (kg) 20.7

Main Components

Description Function
Shell Protection of fiber cable closure
Plug Plugging of cable holes
Thermal shrinkable sleeve Fusing of optic fibers
Sealing material Sealing of optic fiber cable closure
Optic fiber splice tray Fixing of thermal shrinkable sleeve and holding of fibers
Insulating tape Expansion of cable diameter


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
