96 Fibers 3In-3Out FT019 Series Horizontal Fiber Optic Splice Closures

96 Fibers 3In-3Out FT019 Series Horizontal Fiber Optic Splice Closures

Afficher tous les détails

Part Number: FT019H-3IO-96

96 Fibers 3In-3Out FT019 Series Horizontal Fiber Optic Splice Closures

Description

The horizontal (inline) fiber splice closures are produced to provide space and protection for the fiber optic cable splicing and joint. They are with the perfect sealed design which have the function of waterproof and dust proof. We now provide many kinds of horizontal fiber optic splice closres which vary in sizes, fiber cores types, fused fibers quantity. And they are all with good performance and competitive prices.

Specifications

  • Maximum capacity:288
  • Compact size and rugged
  • Suitable for ordinary fiber and ribbon fiber
  • The use of reusable components to open seal in order to ensure a good airtight waterproof performance.
  • The use of high-strength engineering plastic shell that can endure harsh conditions such as vibration, impact, tensile cable distortion and strong temperature changes
  • The scope of application : aerial, direct-buried, wall-mounting, duct-mounting,
  • Does not require special tools, easy to install and open the duplicate.
  • Each packing quantity: 4 pieces
  • Number of Fiber Entry: 3in-3out
  • Installable type of fiber splice tray: 12, 24 or 48cores (optional)

Scope of application

  • This Installation Manual is suit for the Fiber Optic Splice Closure (Hereafter abbreviated as FOSC), as the guidance of proper installation.
  • The scope of application is: aerial, underground, wall-mounting, duct-mounting, handhole-mounting. The ambient temperature ranges from -40℃ to +65℃

Sample Picture

Model Parameter

Product outlook size 555*240*123
Product material quality PC(Polycarbonate)
Product weight Approximately 5kg
Suitable Dia of cable 8-23mm
Fibers/Tray 12 or 24 or 48
Max capacity 96 fibers (Bunchy) ; 288 fibers (Ribbon)
Outside box size 58.5*52*31
Each packing quantity 4 pieces


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
