12 Fiber E2000/APC Singlemode Ribbon Fanout Fiber Optic Pigtail 2m PVC

12 Fiber E2000/APC Singlemode Ribbon Fanout Fiber Optic Pigtail 2m PVC

Afficher tous les détails

Part Number: FT12SM-E20A-RP2-2M-PVC

2M 12-fiber E2000/APC 9/125 Singlemode Ribbon Fan-out Fiber Optic Pigtail with 0.9mm color breakout PVC Jacket

Fiber pigtails are a great solution for fusion splicing inside of a fiber optic enclosure. The ribbon fan-out fiber pigtails come with a partial outer jacket to help protect the tight buffer fibers from being damaged. If space is a premium, the outer jacket can easily be removed, allowing the pigtails to have a tighter bend radius and take up less space.

Connector A E2000/APC Connector B Unterminated
Fiber Category Single-mode (OS2) Jacket Color Yelow
Breakout Diameter 0.9mm Jacket Material PVC
Fiber Count 12 Breakout Length 0.5m
Wavelength 1310nm and 1550nm Durability >1000 Times
Insertion loss 0.3dB Interchangeability 0.2dB
Return loss 50dB Vibration 0.2dB
Operating temperature -40~75C Storage temperature -45~85C

Key Features and Applications

Low insertion loss, Low back reflection lossFlexible and easy to strip fibre bufferingIdentifiable fibre buffer colours under all lighting conditionsReduces installation timeAvoids incorrect patching by possible fiber flipping
Data Centres, premise installationsTelecomunication networksLocal area networks(LAN)Wide area networks(WAN)Indoor Applications

Fiber Optic Pigtail for Fusion Splicing

Fiber pigtail cables provide a fast way to make factory terminations in the field.

OEM Service

F-tone.COM supports customized service, such as fiber type, fiber connector, jacket material, pigtail length for simplex packes fiber optic pigtail. Please feel free to contact [email protected].

Packaging & Labeling

This easy to take and well-protected fiber optical pigtail bag package, blister package or roll package have been labelled and marked by F-tone.COM as default.


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
