10mw Output Power 1550nm SLED Broadband Light Source

10mw Output Power 1550nm SLED Broadband Light Source

Afficher tous les détails

Part Number: FTLED-1550-10

10mw Output Power 1550nm SLED Broadband Light Source

F-tone offers varies standards of Superluminescent Light Emitting Diodes (SLED s) broad band light sources with high stability and reliability as well as a wide wavelength ranging from 650nm to 1650nm. F-tone’s SLEDs have very rich application which includes fiber optical sensors, optical test instuments, biomedical imaging systems and spectrum analyses. Plus, vaires available output powers meet out customers different controls.This 1550nm wavelength SLED broad light source is designed with 1mw, 2mw, 5mw, 8mw, 10mw, 20mw, 30mw output power available to meet your specific use.

Key Features

  • FBG Optical Sensor System
  • Optical Communication
  • Optical Passive device testing
  • Spectrum analyses

Application

  • High Precision ATC and APC Control Circuit
  • High stability and reliability
  • Broadband spectrum

Specifications

Item Unit Parameters
Central wavelength(λ1 -λ2) nm 1550±10
Spectrum width(3dB) nm ≥50
Output power mw 1、 2、5、8、10、20、30
Ripple dB ≤0.2
Output power short term stability dB/min 0.01/15
Output power long term stability dB/hour 0.03/8
Operating mode CW
Fiber Mode Single mode SMF-28
Output connector FC/UPC,FC/APC
Operating temperature ℃ 0~40
Storage temperature ℃ -20~70
Power supply 110/220V AC±10%, 50Hz, 20W
Dimensions (L×W×H) mm 322×220×88

Note:
1.Specifications may change without notice.
2.Devices can be customized to meet your specific use, such as custom optical performance and custom housing or fibers.For more information, please email [email protected] or call us at +1-86-2786-1199

Typical Spectrum




Ordering Information

F-tone custom designs and manufactures high performanceSLED Broadband Light Source to meet your special application. And also, by combining our technical expertise with our extensive micro-optic manufacturing and packaging capability, your volume requirements for components and customized integrated products can be met. We are happy to discuss your requirements. For more ordering and price information, Please contact us at [email protected] or +1-86-2786-1199.

For example: FTLED -M1015S7FP

Series Code Type Display Power Adjustable Operating Wavelength Fiber Type Output Power Connector Type
FTLED M=Module
D=Desk-top		 0=Without
1=With		 0=Without
1=With		 65=650nm
75=750nm
85=850nm
88=880nm
98=980nm
13=1310nm
15=1550nm
16=1650nm
126=1250nm~1650nm
S=Special		 S=Single-Mode Fiber
P=PM Fiber
M=Multi-Mode Fiber		 1=1mw
2=1.5mw
3=2mw
4=3mw
5=5mw
6=8mw
7=10mw
8=20mw
9=30mw
10=Special		 FP=FC/UPC
FA=FC/APC
SP=ST/UPC
SA=FT/APC
LP=LC/UPC
LA=LC/APC
SU=SC/UPC
SC=SC/APC


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
