Part Number: FTOFSM-G657A2-X
G.657.A2 EasyBand® Plus Bending Insensitive Single-mode Fiber 50.4km Length in Spool
EasyBand® Plus bending insensitive single-mode fiber combines two attractive features: excellent low macro-bending sensitivity and low water-peak level. It is comprehensively optimized for use in O-E-S-C-L band (1260 -1625 nm). The EasyBand® Plus's bending insensitive feature not only guarantees L-band applications but also allows for easy installation without excessive care when storing the fiber especially for FTTH networks application. Bending radii in fiber guidance ports can be reduced as well as minimum bend radii in wall and corner mountings.
Applications
● All types of fiber cables with different structures
● High performance optical network operating in O-E-S-C-L band
● High speed optical routes for fiber-to-the-Home networks
● Cables with extreme low bending requirements
● Small-sized fiber cable and optical component
Product standards
EasyBand® Plus bending insensitive single mode fiber meets or exceeds the ITU-T Recommendation G.652.D/G.657.A1/G.657.A2/G.657.B2 including the IEC 60793-2-50 type B1.3/B6.a1/B6.a2/B6.b2 Optical fiber Specification.
Characteristics
● Extremely high bending loss resistance in the 7.5 to 15 mm bending radius range
● Full compatibility with all G.652 fibers for any applications
● Low attenuation satisfying the operation demand in O-E-S-C-L band
● Low PMD satisfying high bit-rate and long distance transmission requirements
● Low bending loss for highly demanding cable designs including ribbons
● Accurate geometrical parameters that insure low splicing loss and high splicing efficiency
● High nd-value satisfying long operational lifetime in minimum bend radius
Specification
| Characteristics | Conditions | Specified values | Units | |
|---|---|---|---|---|
| Optical Characteristics | ||||
| Attenuation | 1310nm | ≤0.35 | [dB/km] | |
| 1383nm(after H2-aging) | ≤0.35 | [dB/km] | ||
| 1460nm | ≤0.25 | [dB/km] | ||
| 1490nm | ≤0.23 | [dB/km] | ||
| 1550nm | ≤0.21 | [dB/km] | ||
| 1625nm | ≤0.23 | [dB/km] | ||
| Attenuation vs. Wavelength Max. α difference |
1285-1330nm, in reference to 1310nm | ≤0.03 | [dB/km] | |
| 1525-1575nm, in reference to 1550nm | ≤0.02 | [dB/km] | ||
| Zero Dispersion Wavelength(λ0) | -- | 1300-1324 | [nm] | |
| Zero Dispersion Slope(S0) | -- | ≤0.092 | [ps/(nm2·km)] | |
| PMD | Maximum Individual fiber | -- | ≤0.1 | [ps/√km] |
| Link Design Value（M=20，Q=0.01%) | -- | ≤0.06 | [ps/√km] | |
| Typical Value | -- | 0.04 | [ps/√km] | |
| Cable Cutoff Wavelength (λCC) | -- | ≤1260 | [nm] | |
| Mode Field Diameter（MFD） | 1310nm | 8.4-9.2 | [μm] | |
| 1550nm | 9.3-10.3 | [μm] | ||
| Effective Group Index of Refraction（Neff ） | 1310nm | 1.466 | -- | |
| 1550nm | 1.467 | -- | ||
| Point Discontinuities | 1310nm | ≤0.05 | [dB] | |
| 1550nm | ≤0.05 | [dB] | ||
| Geometrical Characteristics | ||||
| Cladding Diameter | -- | 125.0±0.7 | [μm] | |
| Cladding Non-Circularity | -- | ≤0.7 | [%] | |
| Coating Diameter | -- | 235-245 | [μm] | |
| Coating-Cladding Concentricity Error | -- | ≤12.0 | [μm] | |
| Coating Non-Circularity | -- | ≤6.0 | [%] | |
| Core-Cladding Concentricity Error | -- | ≤0.5 | [μm] | |
| Curl(radius) | -- | ≥4 | [m] | |
| Delivery Length | -- | Up to 50.4 | [km/reel] | |
| Environmental Characteristics | 1310nm, 1550nm & 1625nm | |||
| Temperature Dependence Induced Attenuation | -60℃ to +85℃ | ≤0.05 | [dB/km] | |
| Temperature-Humidity Cycling Induced Attenuation | -10°C to +85°C, 98% RH | ≤0.05 | [dB/km] | |
| Watersoak Dependence Induced Attenuation | 23°C, for 30 days | ≤0.05 | [dB/km] | |
| Damp Heat Dependence Induced Attenuation | 85°C and 85% RH, for 30 days | ≤0.05 | [dB/km] | |
| Dry Heat Aging | 85℃, for 30 days | ≤0.05 | [dB/km] | |
| Mechanical Specification | ||||
| Proof Test | -- | ≥9.0 | [N] | |
| -- | ≥1.0 | [%] | ||
| -- | ≥100 | [kpsi] | ||
| Macro-bend Induced Attenuation | 10 Turns Around a Mandrel of 15 mm Radius | 1550nm | ≤0.03 | [dB] |
| 10 Turns Around a Mandrel of 15 mm Radius | 1625nm | ≤0.1 | [dB] | |
| 1 Turn Around a Mandrel of 10 mm Radius | 1550nm | ≤0.1 | [dB] | |
| 1 Turn Around a Mandrel of 10 mm Radius | 1625nm | ≤0.2 | [dB] | |
| 1 Turn Around a Mandrel of 7.5 mm Radius | 1550nm | ≤0.5 | [dB] | |
| 1 Turn Around a Mandrel of 7.5 mm Radius | 1625nm | ≤1.0 | [dB] | |
| Coating Strip Force | typical average force | 1.5 | [N] | |
| peak force | 1.3-8.9 | [N] | ||
| Dynamic Fatigue Parameter(nd) | -- | ≥20 | -- | |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
