SC to SC Duplex OS2 Single Mode LSZH FTTA Outdoor Fiber Patch Cable OD 7.0mm Base Station

SC to SC Duplex OS2 Single Mode LSZH FTTA Outdoor Fiber Patch Cable OD 7.0mm Base Station

Afficher tous les détails

Part Number: FTTA-SM-SCU-DX-LSZH

Fiber To The Antenna (FTTA) Singlemode Patch Cable Armored LSZH for Base Station Outdoor Applications

FTTA patch cable is designed for high reliability in heavy industrial and harsh environment applications, including fiber to the antenna solution. FTTA Fiber Cable.

Consisting of Corning fiber cable and LC UPC duplex connectors, the cable features superior crush resistance and a high degree of flexibility with the armored tube. Furthermore, the cable features a flame retardant LSZH jacket which is UV stabilized and highly resistant to chemicals commonly found in industrial environments, also suitable for both indoor and outdoor industrial installations.
Product Specifications
Connector Type SC to SC Polish Type UPC to UPC
Fiber Mode OS2 9/125μm Wavelength 1310/1550nm
Insertion Loss ≤0.3dB Return Loss ≥50dB
Fiber Grade Corning G.657.A1 Min. Bend Radius (Dynamic/Static) 20/10D
Attenuation at 1310 nm 0.36 dB/km Attenuation at 1550 nm 0.22 dB/km
Fiber Count Duplex Cable Jacket Low Smoke Zero Halogen (LSZH)
Cable Diameter (Outer/Inner) 7.0/2.0mm Armored Breakout Length (End A/B) 0.03/0.34m
Tensile Strength (Long Term/Short Term) 400/200N Crush Resistance (Long Term/Short Term) 2200/1100N
Operating Temperature -20~70°C Storage Temperature -40~80°C

Product Spotlight

Superior Flexibility

Corning G.657.A1 bend insensitive fiber

Excellent flexibility for remote traction

Certification & Standards

IEC 61754 series compliant

Qualified to Telcordia GR-326-Core

ISO 9001, Reach, RoHS compliant

Test Assured Program

Insertion loss and return loss testing

End-face inspection

3D interferometer test

Product Highlights

Designed for Outdoor Base Station Construction

This type of specialized fiber patch cable is designed for harsh environment application such as high performance fiber-to-the antenna (FTTA) cabling for current 4G/LTE and 5G network and base station construction connecting AAU and RRU, also suitable for wireless horizontal and vertical cabling in indoor/outdoor environment.

Corning G.657.A1 Fiber

Corning BIF cable can be stapled and bent around corners without sacrificing performance.

Stainless Armored Tube

Hard spiral armored tube makes the FTTA Fiber Cable more stable and higher tensile strength.

Strength Members

Two strength members firm the cable and make it more convenient for pulling when installing.

LSZH Rated Outer Jacket

Jacketed with compounds that emit limited smoke and no halogen when exposed to high heat sources.

Cable Assembly Structure Illustraion


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
