Custom 1xN,2xN Fiber Splitter in FLG Series LGX Cassette, SC/LC, UPC/APC

Custom 1xN,2xN Fiber Splitter in FLG Series LGX Cassette, SC/LC, UPC/APC

Afficher tous les détails

Part Number: LGX-PLC-SL-C

Custom Fiber PLC Splitter 1xN,2xN with Standard LGX Metal Box, SC/LC, UPC/APC

FTTH PLC Splitter Terminal Solution How does the optical singnal transmit from OLT to ONU via PLC splitter

Learn More

Planar Lightwave Circuit (PLC) Splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.

Product Details

Package Style LGX Box Configuration Type 1/2xN
Fiber Type G.657A1 Connector Type SC/LC
Fiber Diameter 0.9mm Polish Type UPC/APC
Operating Bandwidth 1260~1650nm Operating/Storage Temperature -40~85C

Product Highlights

PLC Splitter with Standard LGX Metal Box

  • Eliminate the need for splicing machines and skilled personnel on the field
  • LGX metal box provides a plug-and-play method for inetwork integration
  • Reduce the time and risks during the installation

Perfert Details of LGX Box Splitter

High Degree of Protection

Robust contruction and compact and rugged metal material provides extra strength.

Rounded Corners

Eliminate accidental injury or damage to installers.

Screw-socket Design

Screw-socket design makes the adapter more firmly fixed on the panel, and avoiding the adapter fall off.

Exquisite Packaging

The design and packaging is exquisite to ensure the product in good condition.

Ideal Solution for High Dense Cabling

This design enables fast deployment - factory terminated modular system saves much space, installation time and cost.

A Variety of Applications of Bare PLC Splitter

Important passive component in PON network

Widely used in CATV, FTTH/FTTX, PON network, DWDM and CWDM systems, test equipment, LAN/MAN/WAN network, and more.

Image Part Number ID# Description Price
1RU Rack Mount LGX Fiber Enclosure
FLG-1UFMX 31033 1RU Rack Mount LGX Fiber Enclosure unloaded, holds up to 3 LGX Cassettes US$ 34.00 Add to Cart
2RU Rack Mount LGX Fiber Enclosure
FLG-2UFMX 34034 Customized empty 3-slot 2RU rack chassis to hold 3 pieces standard 2U LGX cassette US$ 73.00 Add to Cart
4RU Rack Mount LGX Fiber Enclosure
FLG-4UFMX 31034 4RU Rack Mount LGX Fiber Enclosure unloaded, holds up to 12 LGX Cassettes US$ 140.00 Add to Cart


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
