SC/UPC Duplex PVC OM4 Multimode Fiber Loopback

SC/UPC Duplex PVC OM4 Multimode Fiber Loopback

Afficher tous les détails

Part Number: LPM-OM4-SC

Single-mode 9/125 Fiber Loopback Cable LC Connector

Fiber Loop back is designed to provide a media of return patch for a fiber optic signal; typically it is used for fiber optic testing applications or network restorations. For the testing applications, the loopback signal is used for diagnosing a problem. Sending a loopback test to network equipment, one at a time, is a technique for isolating a problem.
Fiber Loopback is abosolutely an economical solution for a number of fiber optic test applications.
F-tone Co., Limited supply various kinds of Single Mode and Multimode Fiber Optic Loopback Cables, which are with different connectors including ST, SC, FC, LC, MU, MTRJ etc. Each cable is functionally tested before shipping and is covered by a lifetime warranty.

Key Features

Used in Single-mode 9/125 Fiber Testing Application 100%Functionally tested before shipping Ease and accuracy of insertion as duplex clips hold connectors together 8 inches standard length (Custom length also available upon request) Lifetime Warranty

Mechanical Drawing

Applications

R&D Fiber labs Telecom testing FTTX testing

Specifications

Type: Loopback Module
Fiber: Single-mode 9/125
Connector: LC/PC
Jacket Style: PVC (Yellow)
Durability: Over 500 cycles (<= 0.2 dB change)
Reflectance: minimum of 20 dB



This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
