NTT AT NEOCLEAN-MMC Pen Type Optical Connector Cleaner for MMC-12/24 APC

NTT AT NEOCLEAN-MMC Pen Type Optical Connector Cleaner for MMC-12/24 APC

Afficher tous les détails

Part Number: NTT-ATC-NM-MMC

NTT NEOCLEAN-MMC Pen Type Fiber Cleaner for MMC-12/24 Connectors

The NEOCLEANTMeries of optical connector cleaners uses ultra-fine fibers specially developed for optical connectors. It removes even tiny contaminants that are invisible to the naked eye, without using alcohol. Use NEOCLEAN® to improve work efficiency in optical installation and maintenance, and to enhance the reliability of communication services.

The optical connector cleaner NEOCLEAN series complies with the RoHS Directive.

Features

NEOCLEAN-MMC is an optical connector cleaner specifically designed for MMC connectors.
Its unique guide structure and cleaning mechanism ensure stable contact and reliable end-face cleaning, even in narrow-pitch structures.

Designed specifically for MMC connectors.
Designed for MMC connectors with narrow pitches and diverse shapes, it ensures stable contact with the ferrule end face, enabling thorough cleaning.

A unique guide structure prevents misalignment.
Our unique guide structure prevents misalignment and poor contact during cleaning, ensuring consistent cleaning quality regardless of the operator's skill level.

Low dust generation and uniform cleaning power
Inheriting the proven low-dust design and uniform cleaning mechanism of the MPO cleaner "NEOCLEAN-M," this cleaner ensures reliable cleaning while suppressing contamination buildup on the edges.

Specification

Product name NEOCLEAN-MMC NEOCLEAN-MMC16
Model number ATC-NM-MMC ATC-NM-MMC16
Applicable connectors (polished type) MMC※1 (APC) MMC-16※2 (APC)
Size (mm) 270(L) x 51(H) x 19(W) (excluding attachments)
weight Approximately 53 g
Number of cleanings 580 times or more

*1 NEOCLEAN-MMC supports 12-core and 24-core MMC connectors.
*2 NEOCLEAN-MMC16 supports 16-core and 32-core MMC-16 connectors.


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
