NVIDIA/Mellanox Compatible 400GBASE-SRBD QSFP-DD PAM4 850nm 100m DDM MPO-12/APC MMF Optical Transceiver Module - F-tone

NVIDIA/Mellanox Compatible 400GBASE-SRBD QSFP-DD PAM4 850nm 100m DDM MPO-12/APC MMF Optical Transceiver Module - F-tone

Afficher tous les détails

Transceivers Type

QSFP-DD Optical Transceiver

Specifications

NVIDIA/Mellanox Compatible 400G QSFP-DD SR4 BD PAM4 Optical Transceiver Module (850nm, 100m, MPO-12 APC Connectors, MMF, 0℃ to +70℃, DOM)



NVIDIA/Mellanox Compatible 400GBASE-SRBD QSFP-DD module with MPO-12 APC connectors, max transmitter distance up to 150m over OM5 multi-mode fiber. It is a parallel Quad Small Form-factor Pluggable, double density (QSFP-DD) Bi-Direction optical module. The module accepts eight host electrical data and transmits them in two groups of optical bi-directional lanes (each group contains 4 pairs of optical lanes) to allow optical communication over optical multi-mode fibers. The FT-QDD-400G-SR4.2 module is built with DDM function, which can access operating parameters in real-time. This optical module is suitable for 400G Ethernet and Data Center interconnect.



Part Number FT-QDD-400G-SR4.2 Vendor Name F-tone
Form Factor QSFP-DD Max Data Rate 425 Gbps (8x 53.125 Gbps)
Wavelength 850nm, 910nm Distance 70m@OM3/150m@OM5
Connector MPO-12 APC Cable Type MMF
Transmitter Type VCSEL Receiver Type PIN
TX Power -6.5 to +4dBm Receiver Sensitivity < -8.5dBm
Packaging Technology COB (Chip on Board) Packaging Receiver Overload 4 dBm
Power Consumption ≤12W Modulation Format PAM4
DDM/DOM Supported Temperature 0 to 70°C (32 to 158°F)
Protocols QSFP-DD MSA, IEEE 802.3-2015 Warranty 5 Years

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
