Source Photonics SP-03-IR1-CDFN Compatible OC3-IR1 1310nm 15km EXT DDM Transceiver

Part Number: OSFP-1M31-15

OC3-IR1 SFP 1310nm 15km EXT DDM Transceiver Source Photonics SP-03-IR1-CDFN Compatible

OC-3/STM-1 is a network line with transmission speeds of up to 155.52 Mbit/s (payload: 148.608 Mbit/s; overhead: 6.912 Mbit/s, including path overhead) using fiber optics. This transceiver offers the same function with Source Photonics SP-03-IR1-CDFN and it is fully compatible with Source Photonics devices. Depending on the system OC-3 is also known as STS-3 (electrical level) and STM-1 (SDH). These modules are also used for Fast Ethernet application.

Key Features

• Data-rate of 155Mbps operation
• 15km with 9/125 µm SMF
• Hot-pluggable SFP footprint duplex LC connector Interface
• Class 1 FDA and IEC60825-1 Laser Safety Compliant
• Compatible with SFP MSA
• Compatible with SFF-8472
• Average Output Power:-15～-8dBm
• Receiver Sensitivity:-28dBm
• +3.3V single power supply
• Built-in Digital Diagnostic Function
• Extended temperature range: -5 to 70°C

Applications

• Fast Ethernet
• OC-3 IR-1 /STM-1 (S-1.1)
• ATM Switches and Routers
• Other Optical Links

Ordering Information

Notes

• F-tone also provide other SFP transceivers with different transmission distances, like 100km

Packaging

• Antistatic bag
• Packed on pallets in a box(Default Customer Options)
• Specific Labels as Request
• Seperate white Box for each transceiver

OEM and ODM

Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, F-tone provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for F-tone in the world.

• OEM/ODM order is available
• We can supply OSFP-1M31-15 according to your requirements, and design OSFP-1M31-15 label and packaging for your company. We welcome any inquiry for customized SFP optical transceiver.

Order Procedure

Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
a. Email ([email protected]) us a rough sketch to a detailed drawing.
b. Our engineer will review the project and provide a quotation within 24 hours.
c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.

Shipment

International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.

Save Cost By Buying DWDM SFP From Original Manufacturer F-tone Directly.

F-tone is an professional manufacturer & supplier of SFP transceivers. All of our SFP transceivers are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee SFP transceivers to work in your system and all of our SFP transceivers come with a lifetime advance replacement warranty. If you have questions about SFP optics, please feel free to contact us at [email protected].

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
