Mellanox MMA1T00-HS Compatible 200G Infiniband HDR QSFP56 SR4 850nm 100m MPO-12 APC OM3/OM4 FEC PAM4 Fiber Transceiver

Mellanox MMA1T00-HS Compatible 200G Infiniband HDR QSFP56 SR4 850nm 100m MPO-12 APC OM3/OM4 FEC PAM4 Fiber Transceiver

Afficher tous les détails

Part Number: QSFP56-HDR-200G-SR4M

NVIDIA InfiniBand MMA1T00-HS Compatible QSFP56 200G SR4 Optical Fiber Transceiver (MMF, 850nm, 100m, MPO-12/UPC, DOM)

Mellanox MMA1T00-HS Compatible 200G Infiniband HDR QSFP56 SR4 PAM4 Optical Transceiver Module (850nm MTP/MPO-12 OM3/OM4 100m with FEC DDM)



The NVIDIA InfiniBand MMA1T00-HS Compatible QSFP56 Optical Transceiver is an InfiniBand 200Gb/s Single-port QSFP56, SR4 multimode parallel transceiver using a single, 4-channel MPO-12/UPC optical connector. The parallel multimode, short reach 4-channel (SR4) uses 50G-PAM4 modulation and has a maximum fiber reach of 100-meters using 4 multimode fibers. It is qualified for use in InfiniBand HDR end-to-end systems.


It is the ideal solution for supercomputing, seamlessly integrating into computing and storage infrastructure to ensure efficient high-performance interconnectivity. Used in QM8700/QM8790 switches and ConnectX-6 adapters.

Product Details

Mellanox(HDR) Compatible MMA1T00-HS Vendor Name F-tone
Form Factor QSFP56 Max Data Rate 212.5Gbps
Wavelength 850nm Max Distance 70m on OM3/100m on OM4
Modulation Format PAM4 Host Required FEC
Connector MTP/MPO-12(APC） Voltage Supply 3.3V
Cable Type MMF DDM Support Yes
Transmitter Type 850nm VCSEL Receiver Type PIN
TX Power -6.5~+4.0dBm Receiver Sensitivity < -8.4dBm
Operation Temperature 0 to 70°C (32 to 158°F) Maximum Power < 5W
Protocols QSFP56 MSA, IEEE 802.3bs Application 200G InfiniBand HDR,200G Ethernet Data Center Interconnect

Quality Certifications

Please Note: Installing a third party transceiver does not void your network equipment warranty. Network equipment manufacturers all have guidelines stating that warranty support on their products will not be affected.

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Tout afficher

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Tout afficher

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
