1 Fiber 62.5/125μm Multimode Silica Gel Teflon Tube Sensing Fiber Optical Cable

1 Fiber 62.5/125μm Multimode Silica Gel Teflon Tube Sensing Fiber Optical Cable

Afficher tous les détails

Part Number: SGS-1A1b

Silica Gel Filled Teflon Tube Sensing Optical Cable, 1 Fiber 62.5/125μm Multimode

The silica gel sensing fiber optic cable is very suitable for high temperature resistant and high voltage environment, it could work normally even in the 250 ℃ high temperature environment or 6kv high voltage environment.

The structure of cable is very simple, but the special Silicon jacket and Teflon tube ensure a very good performance of high temperature resistant and high voltage resistant.

Item Details

  • Fiber Count: 1 Fiber

  • Fiber Type: 62.5/125μm Multimode

Cable Structure

Features
  • Use high temperature resistant and high voltage materials will be fiber protected.
  • Normal operation in the 250 ℃ environment, do not affect optical fiber transmission.
  • Normal operation in 6kv high voltage environment, do not affect optical fiber transmission.
  • Meet the requirement of RoHS.
  • Black outer jacket is default.
Application
  • Connection of power system from cabinet to cabinet
  • Normal transmission in the high temperature environment

Package

Package 1
Package 2
Package 1: usually for indoor cable, light weight cables.
Package 2: usually for outdoor cable, heavy weight cables
Usually for each roll, the cable length is 2km, but we could provide customized package for different cable lengths.

Mark


Usually we only attach Test Report on the out package of the cable, but we could also mark as your requirements, such as:
1. Company Name
2. Cross /Net weight
3. Drum No: XX
4. Cable Length : XX

Cable production throughout the chart

Specification

Material Attribute Silica Gel Teflon Hose Kevlar Packaging Weight
High KV 15 — — 300m/drum 5Kg
High Temperature ℃ ≥200~250 ≥230~250 ≥250 500m/drum 8Kg


Teflon Kevlar Silica Gel Wall Thickness Finished Outside Diameter
0.46mm~0.96mm 8×1580（1.80mm） 0.75mm 3.30mm
0.96mm~1.46mm 8×1580（2.40mm） 0.45mm 3.30mm


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
