20km 10/100/1000M Single Fiber 1310nmTx/1550nmRx Stand-alone Management Media Converter

Part Number: SM-1110-SS20U

20km 10/100/1000M Single Fiber 1310nmTx/1550nmRx Stand-alone Management Media Converter SM-1110-SS20U

Stand-Alone Managed media converter equips with remote Web interface, enables network administrators to easily monitor and setup the converter, the transmission speed and duplex through web browsers. Ideal for use in managed networks with low density fiber applications. A Managed Standalone Media Converter is connected across a fiber link to a remote media converter. The copper and fiber link on the managed standalone unit can provide vital information and status to network management tools such as Web. Managed 10/100 Ethernet media converter modules is the smart choice for IT professionals.

If you can’t find what you are looking for, please contact us.

Key Features

• 10/100/1000Base-T(X) to 1000Base-FX Stand-Alone Converter
• Built-in power supply, without power adapter
• Supports Full/Half Duplex, auto-negotiation, MDI/MDI-X on TX ports
• Configurable through console, Web
• Support Vlan and QoS
• Reliable and stable performance
• Free fall, Shock and Vibration Stability
• Standard: Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-SX/LX

Specification

Note: Port Base VLAN is optional, please contact [email protected] for more details.

• UTP port: 1-ports RJ45
• UTP Rate: 10/100/1000Mbps
• Fiber Rate: 1000Mbps
• Fiber Port: Simplex SC, ST, FC, SFP available
• Fiber Wavelength: 1310nmTx/1550nmRx
• Fiber Mode: Singlemode
• Distance: 20km
• Power Supply: Built-in
• UTP cable: Cat. 5/5e/6 UTP cable (the max distance up to 100m)
• LED Indicator: TX LINK, FX LINK, TX ACT, FX ACT, PWR, FDX
• Operation Temperature: 0 ℃~50 ℃(Humidity: 5~90% non-condensing)
• Storage Environment: -25℃~+70℃ (Humidity: 5~90% non-condensing)

Applications

Note: As you can see in the above application picture, Stand-Alone management media converter can separate manage network through Web management.

Label Customized

Note: We can design Fiber Media Converter label for your company according to your requirements. Print any logo in the label is for free. If you need to print your company logo on the equipments, MOQ is 1000pcs.
please contact [email protected] for more details.

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
