ST-18001 MPO Insertion Loss and Return Loss Fiber Testing System

Part Number: ST-18001

ST-18001 MPO Fiber Insertion Loss Return Loss Testing System

18001 MTP/MPO Testing System is the newest product of US, which is special for testing insertion loss and return loss of Multi core / Ribbon Optical fiber. It combine our winding free IL&RL tester 8307, application software of 8201 and Multi-channels Bench-top Power Meter 8124, which is able to test Insertion loss/Return loss of Multi core fibers in the system. The application of “Winding free” technology is a good solution for Multi core fiber which is not able to wrap and with low precision, it greatly improves the efficiency and accuracy of testing IL/RL of Multi core fiber/ Ribbon fiber. While the application software of 8201 offer many kinds of testing modes, testing report, threshold sets and so on. It makes the testing smooth and convenient.

Key Features

Winding free of Return Loss test for multi core fiber, no need to match cream
Automatically test IL&RL of 12 Channels with 2 wavelengths(1310/1550nm)
With large area detector to meet the requirement of testing MTP/MPO Products
With 24 channels of Bench-top power meter
Provide independent 8307 Winding free IL/RL Tester, 8201 Multi-Channels Light source And 8124 Multi-channels power meter to meet the testing requirement of different kinds of optical fiber. It has a good compatibility.
USB port to support software application
Variety of testing mode, such as, only Insertion loss mode, only Return loss mode, only 1310
wavelength mode and so on to meet customer’s requirement
Personalization of testing report design to meet user’s demands.

Real No- mandrel RL tester
Real multi-core no-mandrel RL test
RL/IL Display at same time
For SMF and MMF optional
Power range from +5dBm~-85dBm
12-channel dual-wave IL&RL test.
USB to PC software use
Multi test modes,
CE, FCC, FDA certificated

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
