ST-3105 series Visual Fault Locator

ST-3105 series Visual Fault Locator

Afficher tous les détails

Part Number: ST-3105-XX

ST-3105 Visual Cable Fault Locator

The 3105 is specially designed for field personnel who need an efficient and economical tool for fiber tracing, fiber routing and continuity checking in an optical network during and after installation.
It includes:
Finding the breakpoint, poor connections, bending or cracking in fiber optic cables.
Finding the faults of OTDR

Key Feature

2.5mm universal connector
Operates either in CW or Pulsed
Constant output power
Lower Battery warning
Long battery life (up to 60 hours)
Crash-proof and dust-proof design for laser head
Laser case ground design prevents ESD damage
Burning testing to ensure the reliability.
Portable and rugged, easy to use
Guarantee to CE standards include EMC, EMI, ROHS

Type ST-3105-Pentype
Wavelengths(nm) 650nm
Emitter Type FP-LD
Ouput Power(SM) 1mw,3mw or 10mw(according to customer’s requirement)
Operating model Both CW and Pulse available
Optical Connector Universal 2.5mm Connector(FC,SC,ST)
Power Supply 2 AAA alkaline batteries
Operating Time >50 hours
Operating Temperature(℃) -10~+50
Storage Temperature(℃) -30~+60
Dimension(mm) ￠24X203
Weight（Including battery） 120g(Without battery)

MODEL INCLUDES
ST-3105 Pen-type ST-3105 Pen-type VFL, Alkaline battery, Instruction Manul, Contton Tampon and Soft carrying pouch.


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
