Handheld ST-3109 Fiber Optical Light Source 850/1300nm

Handheld ST-3109 Fiber Optical Light Source 850/1300nm

Afficher tous les détails

Part Number: ST-3109-1

Handheld ST-3109 Fiber Optical Light Source 850/1300nm

Description

ST-3109 optical light source can provide 1 to 4 output wavelengths to meet specific requirements, including the 650nm red source and the 1310/1550nm wavelengths for single mode fiber or the 850/1300nm wavelengths for multimode fiber, as well as other wavelengths according to customer needs. Together with the ST-3208 optical power meter, it is a perfect solution for the fiber optic network characterization.

Note: Together with 2.5mm UPP adapter, FC, SC, ST are all interchangeable.
SC adapter means FC male to SC female fiber adapter.
ST adapter means FC male to ST female fiber adapter.
LC adapter means FC male to LC female fiber adapter.

Features

Provides 1~4 output wavelengths which can be optional according to customer's needs
CW, 2Hz modulation output at 650nm, and CW, 270Hz,1KHz,2KHz modulation output at other wavelengths.
High stability of the output power
Stable output wavelength
Backlight LCD display supports night operation
Compact size and decent appearance
Large LCD, easy operation
Alternative 10 minutes Auto-off function conserving battery life

Application

Maintenance in Telecom
Maintenance CATV
Fiber Optic Lab Testing
Other Fiber Optic Measurements

Recommendation

ST-3109 Handheld Light Source is designed for optimal use with ST-3208 Optical Power Meter for measuring optical loss on both single mode and multimode fiber cable.

Standard Packages

Model Includes
All ST-3109 Models ST-3109 Optical Light Source, Protective Rubber Boot, 3pcs 1.5V batteries,User Manual, Cotton swabs and Soft carrying case.

Kind Note

This price is only for ST-3109 with two output wavelengths(850/1300nm) fiber optic light source. And we also provide ST-3109 fiber optic light source with three output wavelengths and fouroutput wavelengths according to customers' needs.

F-tone is your reliable supplier of fiber optical light source, and all of it have been 100% tested before delivery. And we even provide one year warranty for that. If you have any problems or special requirement or want to buy this ST-3109 fiber optic light source at a large quantity, please feel free to contact us. We will try our best to provide you the best service.


Type ST-3109
perating wavelength(nm) 650 1310/1550 850/1300 850/1300/1310/1550
Emitter Type FP-LD,LED or others please specify
Spectral Width(nm) ≤10
Typical Output Power (dBm) 0 -7dBm for LD, -20dBm for LED
Output Stability ±0.05dB/15mins; ±0.1dB/8hours
Modulation Frequencies CW,2Hz CW,270Hz,1KHz,2KHz
Optical Connector FC/universal adaptor FC/PC
Power Supply Alkaline Battery(3 AA 1.5V batteries)
Storage Temperature(℃) -10~+60
Operating Temperature(℃) -25~+70
Battery Operating time(h) 45
Dimension(mm) 175x82x33
Weight(g) 295




This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
