SM-220 Thermal Fiber Stripper

SM-220 Thermal Fiber Stripper

Afficher tous les détails

Part Number: SUNMA-SM-220

SM-220/230/240 Thermal Fiber Stripper

fiber thermal stripping device design has the advantages of small size, light weight, easy to use and reliable, longitudinal stripping, stripping force is small, peel high fiber quality; blade, durable, and the replacement is convenient,

The linear bearing guide and thermal stripping, ensure no damage to the fiber, easy peeling coating, stripping speed etc..

Specification
Coating strip length Max 30mm
Heating mode Cover Heating
Always heating
Temperature setting 70℃、80℃、90℃、

100,160℃
Optical fiber fixing method Using FH-1, FH-2, FH-4, FH-8, FH-12 series fixtures
Power supply mode Using the adapter to DC12V power conversion
Size 118.5(L) X 46(D) X 31.5(H) mm
Weight 300g
Environmental requirements The temperature of 0-40 DEG C below 85%


Ribbon Fiber Thermal Stripper SM220


Li-on Battery Fiber Thermal Stripper SM230


Dia 0.9mm Fiber Thermal Stripper SM240


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
