Mellanox MCP1660-W00AE30 Compatible 400G QSFP-DD to QSFP-DD PAM4 Passive Direct Attach Copper Twinax Cable 0.5m (1.6ft)

Mellanox MCP1660-W00AE30 Compatible 400G QSFP-DD to QSFP-DD PAM4 Passive Direct Attach Copper Twinax Cable 0.5m (1.6ft)

Просмотреть всю информацию

Part Number: 400G-QSFP-DD-DAC0.5M

Mellanox MCP1660-W00AE30 Compatible 400G QSFP-DD DAC (QSFP-DD to QSFP-DD PAM4 Direct Attach Cable 30AWG 0.5-meter)

400G QSFP-DD passive copper cable assembly feature eight differential copper pairs, providing four data transmission channels at speeds up to 56Gbps(PAM4) per channel and meets 400G Ethernet and InfiniBand Enhanced Data Rate(EDR) requirements. Available in a broad range of wire gages-from 28AWG through 30AWG-this 400G copper cable assembly features low insertion loss and low cross talk.

Product Details

Mellanox Compatible MCP1660-W00AE30 Vendor Name F-tone
Connector QSFP-DD to QSFP-DD Max Data Rate 400Gb/s
Wire Gages AWG 30 Cable Length 50cm (1.6ft)
Jacket Material PVC (OFNR) Minimum Bend Radius 35mm
Operation Temperature 0~ 70 ～C (32 to 158～F) Modulation Format PAM4
Protocols IEEE 802.3bj and IEEE 802.3cd Application 400G Ethernet and InfiniBand EDR


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Посмотреть все

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Посмотреть все

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
