MDC/UPC to MDC/UPC OS2 Singlemode 2-Port Plastic Fiber Optic Adapter without Flange

MDC/UPC to MDC/UPC OS2 Singlemode 2-Port Plastic Fiber Optic Adapter without Flange

Просмотреть всю информацию

Part Number: AD-MDC-MDC-SM-FM

Fiber Optic Adapter MDC to MDC OS2 Singlemode without Flange

A fiber optic adapter, sometimes also called a coupler, is a small device designed to terminate or link the fiber optic cables or fiber optic connectors between two fiber optic lines. MDC/UPC Adapter can connect two MDC connectors precisely. The US Conec 2-port adapter is designed to fit through the same panel cutout defined for duplex LC adapters, allowing an instant 2x of the current FHD® Multimedia Panel connector density by simply removing the LC duplex adapters and installing the MDC adapters.

Features

● 2x Fiber Cabling Density over Duplex LC Adapters

● ≤0.2dB (Typical) Low Insertion Loss

● Stainless Steel Clips for Tool-less Snap-in Installation

● Compatible with Standard LC Duplex Adapter Panel and FHD® Multimedia Panel

● Apply to 200G/400G QSFP-DD/QSFP Hyperscale Data Centers

Specifications

Connector Type US Conec MDC-MDC Body Style 2-Port
Polish Type UPC Fiber Mode OS2 9/125μm
Insertion Loss ≤0.2dB Durability 200 times
Mounting Type Reduced Flanged Alignment Sleeve Material Ceramic
Color Blue Flammability Rate UL 94V-0
Package Quantity 1 Pc RoHS Compliancy Status Compliant
Operating Temperature Range -40 to 75℃(-40 to 167℉) Storage Temperature Range -40 to 75℃(-40 to 167℉)


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
