Part Number: AT-MPO-A-8SM-x
MPO Fixed Fiber Optic Attenuator (Singlemode, Male to Female, MPO APC, Key-Up to Key-Down, Type A, 8 Fiber, 1~25dB)
Fiber optic attenuators reduce the optical fiber power by a certain level within the fiber-optic network. Fiber Attenuators are usually used when the signal arriving at the receiver is too strong and may overpower the receiving elements. This may occur because of a mismatch between the transmitters/receivers (transceivers, media converters), or because the media converters are designed for a much longer distance than for which they are being used. Sometimes, attenuators are also used to stress test a network link by incrementally reducing the signal strength (increasing the dB attenuation) until the optical link fails, thus determining the signal’s safety margin.
F-tone MPO fiber attenuator contains doped fiber and is suitable for operation at 1310nm and 1550nm. Fixed attenuation values are available in 1dB increments from 1 to 25 dB. We have a mature attenuator production process and can fully meet customer needs. Each MPO attenuator is shipped with a test report that makes it easy for customers to check the optical performance quickly.
Features
• Low Back Reflection
• Accurate Attenuation
• Compatible with current conventional Singlemode fiber
• 100% factory tested
Specification
| Connector Type | MPO-8/APC | Attenuation Value | 1~25dB |
|---|---|---|---|
| Fiber Mode | Singlemode | Operating Wavelength | 1260~1610nm |
| Insertion Loss | ≤0.2dB | Return Loss | ≥55dB |
| Gender Type | Female to Male | Attenuation Tolerance | (1-10dB) ±1, (11-25dB) ±10% |
| Ferrule Type | Zirconia Ceramic | Compliance | RoHS compliant |
| Applications | Optical Telecommunication Network CATV, LAN, MAN, and WAN application Testing Device Accessory Fiber optical sensor |
Environment | Operating: -20°C to 70°C Storage: -40°C to 85°C Humidity: 95%RH |
Ordering Information
| Part Number | Description |
|---|---|
| AT-MPO-A-8SM-x | MPO/APC Male to Female Singlemode Plug-in Fixed Fiber Optic Attenuator (x=1~25dB) Key-Up to Key-Down, Type A,8 Fiber |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
