Source Photonics SPL-53-MR-IR1-IDFQ Compatible 2.5Gbps TX1550nm/RX1310nm BiDi SFP 15km RGD Transceiver

Part Number: BSFP-2G53-15A

2.5Gbps BiDi SFP TX1550nm/RX1310nm 15km RGD Transceiver Source Photonics SPL-53-MR-IR1-IDFQ Compatible

The SFP BIDI transceivers are small form factor pluggable module for Gigabit Ethernet 1000BASE-BX-U and Fiber Channel single fiber applications by using 1310nm/1550nm transmitter and 1550nm/1310nm receiver. This transceiver offers the same function with Source Photonics SPL-53-MR-IR1-IDFQ and it is fully compatible with Source Photonics devices. It is with the SFP 20-pin connector to allow hot plug capability. The transmitter section uses a class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated B type/A type detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC. The SFP BIDI transceivers are designed to be compliant with SFF-8472 Multi-source Agreement (MSA).

Key Features

• Support 2.5Gbps Data Link
• 1550nm FP TX/1310nm RX
• 15km with 9/125 μm SMF
• Single 3.3V Power Supply and TTL Logic Interface
• Hot-Pluggable SFP Footprint Simplex LC Connector Interface
• Class 1 FDA and IEC60825-1 Laser Safety Compliant
• Compliant with SFP MSA Specification
• Compliant with Digital Diagnostic Monitor Interface SFF-8472
• Average Output Power: -5~0dBm
• Receiver Sensitivity: -18dBm
• Industrial temperature range: -40 to 85°C

Applications

• Fiber Channel Links
• WDM Gigabit Ethernet Links
• FTTX Application
• Other Optical Links

Ordering Information

Notes

• F-tone also provide other BIDI SFP transceivers with different transmission distances, like 80km.

Packaging

• Antistatic bag
• Packed on pallets in a box(Default Customer Options)
• Specific Labels as Request
• Seperate white Box for each transceiver

OEM and ODM

Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, F-tone provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for F-tone in the world.

• OEM/ODM order is available
• We can supply BSFP-2G53-15A according to your requirements, and design BSFP-2G53-15A label and packaging for your company. We welcome any inquiry for customized BIDI SFP optical transceiver.

Order Procedure

Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
a. Email ([email protected]) us a rough sketch to a detailed drawing.
b. Our engineer will review the project and provide a quotation within 24 hours.
c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.

Shipment

International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.

Save Cost By Buying BIDI SFP From Original Manufacturer F-tone Directly.

F-tone is an professional manufacturer & supplier of BIDI SFP transceivers. All of our BIDI SFP transceivers are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee BIDI SFP transceivers to work in your system and all of our BIDI SFP transceivers come with a lifetime advance replacement warranty. If you have questions about BIDI SFP optics, please feel free to contact us at [email protected].

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
