1 Fiber 960/1000µm Core/Cladding Step Index PMMA 8.0 mm Double Jackets Simplex Plastic Fiber

1 Fiber 960/1000µm Core/Cladding Step Index PMMA 8.0 mm Double Jackets Simplex Plastic Fiber

Просмотреть всю информацию

Part Number: C1000-1-8.0V

8.0mm Double Jackets Simplex Plastic Fiber, 1 Fiber Step Index PMMA, 960/1000µm Core/Cladding

Plastic Optical Fiber (POF) (or fibre) is an optical fiber which is made out of plastic. In large-diameter fibers, 96% of the cross section is the core that allows the transmission of light. It is commonly used for much high-fast data transmission, FTTH, intelligent network of home and office, automobile, intelligence, industry control and monitor system, military communication, etc.

Traditionally PMMA is the core(960μm)material, and fluorinated polymer are the cladding (1000μm)material, and the double jackets is 8.0mm.

Item Details

  • Core Diameter: 960μm

  • Cladding Diameter: 1,000μm

  • Jacket Diameter: 8.0mm

  • Fiber Core Material: PMMA

  • Fiber Cladding Material: Fluorinated Polymer

  • Jacket Material: PE

  • Optical Instruction: Step type

  • Numerical Aperture: 0.5

  • Core Refractive Index: 1.492

  • MOQ Length: 500m

Features
  • Cheapness, lower cost for maintenance, saving cooper resources, energy-saving and environment protection.
  • Immune to electromagnetic wave radiation, no noise effect, good capacity of resisting disturbance.
  • Low weight, flexible, high resist, flutter and determinate cleavage, durability.
  • High bandwidth, high speed, good performance.
  • Close coupling, high illumination, stable attenuation.
  • Easy installation, needlessness for special tools and fusion welding, and cut at will by your request.
  • Waterproof, damp-proof, anti-magnetic, free of magnetic and thunders.
Application
  • High-fast data transmission
  • FTTH application
  • Intelligent network of home and office
  • Automobile, intelligence, industry control and monitor system
  • Military communication

Package

Package 1
Package 2
Package 1: usually for indoor cable, light weight cables.
Package 2: usually for outdoor cable, heavy weight cables
Usually for each roll, the cable length is 2km, but we could provide customized package for different cable lengths.

Mark


Usually we only attach Test Report on the out package of the cable, but we could also mark as your requirements, such as:
1. Company Name
2. Cross /Net weight
3. Drum No: XX
4. Cable Length : XX

Cable production throughout the chart

Specification

Model Number C1000-1-8.0V
Core Diameter 960µm
Cladding Diameter 1,000µm
Jacket Diameter 8.0mm
Working Temperature -45~+75℃
Jacket Material PE
Wavelength 650nm Visible Range

Order Information

Product Code Inner Dia.(MM) Outer Dia. (MM) Jacket materials Attenuation (db/km) N.A Operation Temp(°C) Length of spool (M)
C250-1 0.25 1.0±0.07 Black PE ≤350 0.5 -45~75 1500
C500-1 0.5 1.0±0.07 Black PE ≤200 0.5 -45~75 1500
C750-1 0.75 1.0±0.07 Black PE ≤200 0.5 -45~75 2500
C1000-1 1 2.2±0.07 Black PE ≤200 0.5 -45~75 2500
C1000-2 1.0*2 2.2*2±0.1 Black PE ≤200 0.5 -45~75 1250
C1500-1 1.5 3.0±0.07 Black PE ≤200 0.5 -45~75 700
C2000-1 2 3.8±0.07 Black PE ≤200 0.5 -45~75 350
C3000-1 3 5.0±0.07 Black PE ≤200 0.5 -45~75 150
C1000-1-4.0V 1 4.0±0.1 Black PE/PVC ≤200 0.5 -45~75 1000
C1000-1-5.0V 1 5.0±0.1 Black PE/PVC ≤200 0.5 -45~75 1000
C1000-1-6.0V 1 6.0±0.1 Black PE/PVC ≤200 0.5 -45~75 500
C1000-1-7.0V 1 7.0±0.1 Black PE/PVC ≤200 0.5 -45~75 500
C1000-1-8.0V 1 8.0±0.1 Black PE/PVC ≤200 0.5 -45~75 500


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
