Corning SMF-28e+ 9/125/250µm Single-mode Bare Fiber II per Km

Corning SMF-28e+ 9/125/250µm Single-mode Bare Fiber II per Km

Просмотреть всю информацию

Part Number: CORNING-SMF28e+200Kpsi

Corning SMF-28e+ 9/125/250µm Single-mode Bare Fiber II per Km

"The price above is for one kilometer length"

Corning SMF-28e+ addresses the transmission potential of full spectrum, optical transmission by eliminating high attenuation in and around the water-peak region (1360nm–1460nm). This premium attenuation fiber is suitable for transmission applications in the access and metropolitan/access application spaces.

SMF-28e+ fiber is suitable for various applications with link lengths less than 80km and data rates around 2.5Gbps. While providing compatibility with carriers' legacy systems, SMF-28e+ fiber is optimized for various CWDM applications and provides flexibility and versatility in network design, as it enables the use of the full transmission window.

Item Details

  • Fiber Count: 1 Fiber
  • Core Size: 9μm
  • Cladding Size: 125μm
  • Jacket Size: 250μm
  • Fiber Type: Corning SMF-28e+
  • Fiber Screening: 200Kpsi

Features
  • In compliance with or exceeding the industry's most stringent requirements, including:
    ITU-T G.652 (Categories A, B, C & D)
    IEC Specifications 60793-2-50 Type B1.3
    TIA/EIA 492-CAAB
    Telcordia's GR-20
  • Confidence in long-term performance.
  • Suitable for various applications with link lengths less than 80km and data rates around 2.5Gbps.
  • Optimized for various CWDM applications.
  • Versatility in 1310nm and 1550nm applications.
  • Provides flexibility and versatility in network design.
  • The entire fiber length is subjected to a tensile proof stress ≥100kpsi(0.7 GN/m2)).
Application
  • Suitable for transmission applications in the access and metropolitan/access application spaces
  • Widely used in the transmission of voice, data, and video services

Corning SMF-28e+ 9/125/250µm Single-mode Bare Fiber II


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
